[Fig. 5.4.2-1] [Fig. 5.4.2-2]
[Fig. 5.4.2-3]
5.4.2 EMB Parameter Setting
<Fig. 5.4.2-1>, <Fig. 5.4.2-2>, and <Fig. 5.4.2-3> are the screens showing the parameter setting. For setting, use
the number keys to enter the desired values within the scope same as the basic setting.?
Press , to view the next menu.
turns back the set values to default values of the operating program.
When is pressed, the next menu is displayed.
<Fig. 5.4.2-1>, the initial screen, shows eight setting menus. When is pressed first, the following eight
setting menus appear as in <Fig. 5.4.2-2>. Press again and the last embroidery parameter setting menus
appear as in <Fig. 5.4.2-3>. When is pressed once again, the initial screen returns as in <Fig. 5.4.2-1>.
is used to select menu. Press to exit from setting.
