22
8.1.2) For starting embroidery and stopping the machine
You can use START and STOP switches during machine operation in the following cases.
1) For starting or stopping the embroidery work
2) For moving the frame backward during embroidery work stop
Switch Machine Operation
Press START Machine starts and embroidery work begins.
Hold START Machine “inching (see Note1)”until you release the START switch.
Press STOP Machine stops.
Switch Machine Operation
Press STOP Frame moves backward in selected frame movement units (see Note 2)
Hold STOP Frame starts to move backward.
If you release STOP before the machine goes 10 of the selected
stitches, the machine will stop immediately (the machine moves in the
selected frame movement units). If you release the switch after the
machine traveled 10 of the selected stitches, the machine will continue
to move back.
Press STOP Press STOP again and the machine will stop moving backward.
1) Non-stitching (floating) function is not available in the initial menu.
2) To perform floating at the start of embroidery, press STOP switch. The machine will then go
into STOP MODE. Select FLOAT and set the number of non-stitching desired in the sub
menu.
NOTE
3) For backward non-stitching during embroidery work stop
Same as START/STOP during embroidery work stop
1) “Inching” refers to low-speed embroidery at 100 rpm range, performed for stable stitching
when the machine is re-started after stop.
2) “Frame movement unit” refers to the “13. BK STITCH UNIT” in “Parameter Set-Up”. You can
select from 1 to 10 stitches (by 1 stitch).
NOTE
