Swift Tourer User Manual

MAINTENANCE
188
AL-KO ATC CONTROL SYSTEM
Display
Colour
ATC
Condition
Diagnosis What to do Outcome Status
Green ATC Active Everything
Ok
Green
Flashing
ATC Active Self test
incomplete
Drive forward
to detect
movement
to complete
self test and
recheck LED.
Green (
Constant)
Ready for
journey
Red ATC
Inactive
Possible to
continue
journey
Remove 12S
or 13 Pin
plug and wait
5 seconds.
Reconnect
plug.
Green
Red
Ready for
journey
ATC Error
logfile memory
exceeded.
Caravan can be
towed, but ATC
will not apply
caravan brakes
in the event of
instability.
See below *
Red flashing ATC has
detected a
fault.
Do not
continue
a fault
with ATC
connected
Remove 12S
or 13 Pin
plug and wait
5 seconds.
Reconnect
the plug
Green
Red
(flashing)
Ready for
journey
ATC faulty,
and cannot be
driven. Remove
push-rod as
shown on page
5. Consult
AL-KO, see back
page for details.
LED not
working
ATC has no
power
Check push
rod position
as shown
LED faulty
on page
5 before
continuing
journey.
Remove 12S
or 13 Pin
plug and wait
5 seconds.
Reconnect
the plug.
Check for
constant
live - refer
to system
requirements.
Green
LED not
working
Ready for
journey
If power ok,
check push rod
position: Red
line visible - do
not drive vehicle.
Red line not
visible - possible
to continue
journey but
consult AL-KO
see back page
for details.
