FITTED EQUIPMENT
94
TRUMA DIGITAL TIMER CONTROL
Use
Do not use electrical devices for purposes
other than those stated by the manufacturer.
Repairs
Do not repair or modify the device. Please
contact your dealer or the Truma Service (see
service manual or www.truma.com).
Accessories
Only use accessories and additional devices
that are supplied or recommended by the
manufacturer.
Intended use
The CP 25-UK is a digital operating / display
and control unit for the Combi Boiler.
The device is designed to be installed in
caravans and motorcaravans.
Initial operation or activation after a
power cut
After the operating voltage has been
connected , the unit will beep and the display
remains dark. To switch on, press the key 4
and the main screen will appear.
Function description
Note: More details regarding the operating
modes can be found in the operating
instructions of your Combi.
Main Screen
Room temperature: Display on when the
heater is active
Timer: Display on when the timer is active
Clock: Only if the clock has been set,
otherwise the Truma logo will appear
in the display
Status of the heater :
H: Set room temperature (e.g. 18°C)
EG: Energy selection (E = Electro, G = Gas)
W: Set water temperature
Selection Key upwards to select functions
or set values
Selection key downwards to select
functions or set values
Selection key backwards to select values
Selection key forwards to select values
On / Off
• Display and heater is switched on and /
or off
• The clock is shown when the time is set
• After an interruption in the operating
voltage, the display and the heater are
switched off. If the time is shown, this
needs to be set.
Green LED shines when the heater is on
Greed LED flashes when the heater is
after-running
Red LED shines when there is a malfunction
Manual mode
• In manual mode, the heater is controlled
via the 4 keys below the display.
• It is not necessary to set the time because
the Truma logo is shown in the display
instead of the time.
