Item # Description Part #
1 3/4-16 Jam Nut NB175
2 1.5x.761x.098x.134 Belleville Washer AS155
3 Blade Pulley, 5" 20651
4 Spacer - 3/4 ID x 1 Powder Metal 12823
5 3/4 ID X 1 1/4 OD 18 GA Washer NB179
6 Blade Bearing B98
7 Blade Shaft 6"- Long Shoulder 9078
8 5/16-18 Serr. Flange Nut NB170
9 Blade Bearing Housing 9091*
10 5/16-18 X 3/4 Serr. Flange Bolt NB596
11 3/4 ID X 1 3/4 OD Flat Washer B98W
12 3/8-24 Two Way Locknut NB216
13 Blade Mount Plate 9008
14 Blade 24" 9016
15 3/8-24 X 1 Bolt NB238
16 SP Washer Bellvl. PLN .413 X .945 X .118 NB607
17 3/8-24 X 1 Engine Bolt Locktite NB238N
18 Blade Driver Assembly 10712
12
BLADE DRIVER ASSEMBLY
BRAKE ASSEMBLY
When ordering replacement parts
*USE PAINT CODE: TK=BLACK
Item # Description Part #
1 Nut - Jam, Nyloc 3/8-16 NB207
2 Washer - SAE Flat 3/8 NB272
3 Finger for Belt Release T30F
4 Nut - Jam 3/8-16 NB174
5 Pulley - Idler Clutch, 2 3/4 OD T30V
6 Nut - 2 Way Lock 3/8-16 NB280
7 Idler - Blade Weldment 10668*
8 Bolt - HTC, 3/8-16 X 2 NB231
9 Pulley - Idler, OD3.25 X ID3/8 B527
10 Bolt - 1/2-13 X 3 HCC NB131
11 Nut - Jam Lock, 1/2-13 2-Way NB121
12 Bolt - 3/8-16 X 2 1/2 HTC NB619
13 Washer - Hardened 3/8 NB196
14 Spacer - .625 OD X 1.25 8072*
15 Spring - Torsion Brake BT297
16 Pad - Brake, Cylindrical 9114
17 Spring - Brake Pad Retainer BP370S
18 Chain - Sgl Jk Chn, Zps, Sz12, 16# AS080
19 Bolt - 3/8-16 X 1 1/2 HCC NB107
To Next Page
