11
Item # Description Part #
1 5/16-18 Serr. Flange Nut NB170
2 Rear Cover 10679*
3 Anti Reverse Arm 10680*
4 Spacer B99S
5 5/16-18 X 3/4 Serr. Flange Bolt NB596
Item # Description Part #
1 Lever - Blade Engagement Weldment 19444*
2 Weldment - Handle 21078*
3 Nut - Nyloc 1/4-20 NB180
4 Grip - Handle 7826
5 Control - Latching Drive 19208
6 Nut - Nyloc 5/16-18 NB181
7 Washer - SAE Flat 1/4 NB274
8 Lever - Engagement 10685*
9 Plate - Blade Lever Cable 10713*
10 Bolt - Serrated Flange 5/16-18 X 3/4 NB596
11 Bolt - 1/4-20 X 2 3/4 19455
12 Bolt - 1/4-20 X 1 3/4 NB278
13 Cable - Transmission 19209
14 Bolt - MSC 1/4-20 X 1/2 NB113
REAR COVER ASSEMBLY
HANDLE BAR & LEVER ASSEMBLY
When ordering replacement parts
*USE PAINT CODE: TK=BLACK
