MO’ BASS SPECIFICATIONS

Note:

All measurements were taken with a line voltage of 120VAC.

All noise specifications are "unweighted."

All voltages and watts are "RMS."

All measurements taken with tone controls set flat, Aural Enhancer at minimum, all effects disengaged.

Power Ratings (minimum)

Bridge/Mono Mode

900 Watts @ 4 Ohms

650 Watts @ 8 Ohms

440 Watts @ 16 Ohms

(minimum load = 4 Ohms)

Stereo Mode (per side)

600 watts @ 2 Ohms

400 watts @ 4 Ohms

250 watts @ 8 Ohms

150 watts @ 16 Ohms

(minimum load = 2 Ohms)

Frequency Response (Power Amplifier):

-3 dB @ 10Hz to 40kHz

Sensitivity (full output under clipping, 8 ohm load, 100 Hz)

Passive Input Jack: 42 millivolts

Active Input Jack: 84 millivolts

Power Amplifier (Effects Return Jack "in"): 6 volts peak-to-peak

Input Impedance

Passive/Active Input: 1 Meg Ohms

Active Input: 47K Ohms

Effects Returns: 27K Ohms

Output Impedance

Effects Sends: 220 Ohms

Tuner Output: 220 Ohms

XLR Balanced Out: 750 Ohms

Signal To Noise Ratio:

-88 dB (<10 millivolts typical)

Equivalent Input Noise:

15 nanovolts per root/hertz

Dimensions (measured from the rack ears back)

19" W x 5 " H x 13" D (the front panel flanges add 1")

Weight: 29 lbs.
