mm
mm
TOL
OK
+
MODE
mm
MODE
mm
MODE
mm
TOL
mm
TOL
11
E
6.2 Use of the buttons and :
It is also possible to enter or modify the nominal value or the tolerance limits by prolongedly pressing (>2s) the a n d /
or button :
Enter the
nominal rating
Enter the
lower interval
Enter the
upper interval
(see chap. 7) (see chap. 7) (see chap. 7)
Note :
- It is also possible to display the tolerance limits when the instrument is operating in MIN, MAX or DELTA (TIR) mode.
- If no tolerance limits have been dened by the user, the instrument will only display the tolerance limit indicators but will
not turn on the indicator lights (red - green - yellow).
- In case of measuring internal ratings, you can cross the indicators (red and yellow) by reversing the order of entering the
tolerance intervals (upper interval < lower interval).
