Sylvac S Dial WORK Smart - Specifications

13. Specifications
Measurement range: 12.5mm 25mm 50mm 100mm 150mm
Max error (10µm resolution):
10µm 10µm 20µm 20µm 20µm (±1 digit)
Max error (1µm resolution):
3µm 4µm 5µm 6µm 10µm
Max error (0.1µm resolution):
1.8µm 2.2µm --- --- ---
Repeatability: 2µm 0.5µm (model 0.0001mm scale)
Weight: 119g 123g 161g 208g 265g
Measurement force (standard): 0.65-0.9N 0.65-1.15N 1.25-2.7N 1.6-3.5N 2.2-5.7N
Max. speed of travel: 1.7m/s
No. of measurements / second: up to 10 meas/s MIN/MAX mode: up to 20 meas/s
Measurement unit: metric/english (Inch)
Maximum Preset (10µm resolution):
±9999.99 mm / ±399.9995 IN
Maximum Preset (1µm resolution):
±999.999 mm / ±39.99995 IN
Maximum Preset (0.1µm resolution):
±99.9999 mm / ±3.999995 IN
Measurement system: Sylvac inductive system (patented)
Power: 1 x 3V lithium battery, type CR2032, 220mAh
Average battery life:
8’000 hours (with Bluetooth
®
enabled, see chapter 6.1)
Data output: RS232 compatible / Bluetooth
®
4.0 (see chapter 6)
Working temperature (storage): +5 to +40°C (-10 to +60°C)
Electromagnetic compatibility: as per EN 61326-1
IP rating (in accordance with IEC60529): IP 54 / IP 67 (depending on model)
Fixing and space envelope: Ø8h6 (3/8’’), interchangable M2.5 (4-48-UNF) probe (as per DIN 878)
