18. Technical specifications
18.1. Common Specifications
Standard measuring range 0-30mm, 30-66mm, 66-102mm, 100-136mm, 125-161mm
0-1.2’’ , 1.2-2.6’’, 2.6-4.0’’ , 4.0-5.3’’ , 5.0-6.3’’
Resolution 1μm
Measuring force (0-25/30mm) Ajustable 5N/10N. 5N with disk-anvils.
Measuring force (long ranges) 10N standard
Advance 10mm/rotation
Number of refreshments display 8/s
Measuring system Inductive Sylvac System
Power supply Battery CR2032
Average consumption 60μA (continuous)
Standby consumption 12μA
Average autonomy (automatic standby, no data loss) 10’000 hours (Bluetooth
®
see cap. 15.3)
