24
17. SPECIFICATION
Model
Item Specification
AW05W-6/AW05W1-6/AW05W-D/AW05W-S/AW05W-F
Length 1870mm
Width 698mm
Height 1140mm
Wheel base 1325mm
Net Weight 99kg (Front:40kg Rear:59kg)
Model Single cylinder,4- stroke, forced air cooled engine
Fuel required Unleaded gasoline
Displacement 49.5 c.c.
Compression ratio 11.8 :1
Maximum net power output 2.35 kw/8500 rpm
Net Maximum torque 2.91 N.m/6500 rpm
Idling speed 2100±100 rpm
Valve clearance: IN/EX 0.03/0.05(±0.02) mm
Starting methods Kick & electrical starter
Front shock absorber Telescopic fork
Rear shock absorber Unit swing
Clutch type Auto centrifugal type
Transmission C.V.T.
Front tire 110/70-12(47J)
Rear tire 120/70-12(51J)
Rim type Aluminum
Tire pressure
Front: STD 2.00 kg/cm
2
,
Rear: STD 2.00kg/cm
2
for 1 person, 2.25kg/cm
2
for 2 persons
Front brake Disk type (Ø 190 mm)
Rear brake Drum type (Ø 110 mm)
Head lamp(high, low) HS1 12V 35/35W
Front position lamp 12V 5W
Front/ Rear direction
indicator
12V 10W
Rear position lamp/Stop
lamp
12V 5W/12V 21W
Licence light 12V 5W
Engine oil capacity 0.80 L (0.75 L for change)
Transmission oil capacity 100±5c.c (90c.c for change)
Fuel tank capacity 5.0L
Fuse 10A & 15A
Spark plug A7RC
Battery capacity 12V 6Ah(closed type, maintenance-free battery)
Air cleaner Paper type
