CAUTION:
Do not wipe plastic components, e.g. instrument panel, headlight, with organic solvents such as
gasoline…etc to avoid damaging these components.
1. Fuel Gauge
The pointer in this gauge shows how much fuel remains in the tank.
The pointer stays in “E” position when key switch is turned to “OFF.”
When key switch is turned to “ON”, and the “pointer” also in “E” position (red area). Refuel
immediately.
2. Turn Signal Indicator
The left or right Indicator will be flashing according to the operated directions of turn signal light switch
when it is turned on.
3. High Beam Indicator (If installed)
This indicator comes on with high beam headlight is turned on.
4. Engine Oil Warning Light
Turn the main switch to the “ON” position, if the oil warning light comes on continuously, this indicates
the engine oil level is too low, add oil as required.
WARNING:
! To continue drive the vehicle under low oil level condition will result in an engine seizure due to lack
of lubrication of engine parts. It is therefore very important to bring your vehicle to your dealer for an
oil replenishment immediately whenever the warning light comes on continuously.
! Use only 2-cycle engine oil meeting Japanese Automobile Standard Organization FC specifications.
Otherwise, this company will not assume any responsibility for damages resulted from using
substandard engine oil.
※Recommended oil: SYM EXTRA 2X oil.
5. Spe
edometer
This shows your speed in kilometers per hour
(km/h) and in mileage per hour (mph).
6. Odometer
This odometer shows the total kilometers this
motor has been driven.
CAUTION:
Observe the speed limit to ensure drive safety.
7-1. Clock
Set time in 24 hour mode.
“M” – mode bottom: Press the “M’ bottom, the clock order shows “Time mode”, “Hour setting mode”,
“Minute setting mode”, ”Second setting mode”. Final back to the “time mode”.
“S” – set bottom: At “Hour setting mode” or “Minute setting mode” or ”Second setting mode”. Press
the “S” bottom once, numerical can be increase. If keeping on pressing for 2
seconds can accelerate the adjustment. Until to set free the bottom. (At “Second
setting mode”, the colon ”:” in the center will be flash for 1 seconds.
7-2. Clock
Please check the appendix for BK05W-6 series speedometer.P32
