SymCom PumpSaver Plus 233P User Manual

SPECIFICATIONS
Functional Specifications
Adjustments/Settings
Overcurrent
125% of calibration point
Underload (dry-well)
Adjustable (70-90% of calibrated run power)
Overvoltage
233P, 233P-1.5
265VAC
111P
132.5VAC
Undervoltage
233P, 233P-1.5
190VAC
111P
95VAC
Number of restarts allowed in 60
second period (rapid-cycling)
4
Trip Delay Times
Overcurrent
5 seconds
Dry-well
4 seconds
Dry-well Optional*
8 seconds
Restart Delay Times
Over/undervoltage
2 seconds
All other faults
Manual, 2-225 minutes
Input Characteristics
Supply Voltage
233P, 233P-1.5
230VAC
111P
115VAC
Load Range
233P
1/3 – 3 hp
233P-1.5
1/3 – 1.5 hp
111P
1/3 – 1 hp
Frequency 50/60Hz
(NOTE: 50Hz will increase all delay timers by 20%)
Output Characteristics
Output Contact Rating-SPST
233P
3hp @ 240VAC (17 Amps max.)
233P-1.5
1.5hp @ 240VAC (10 Amps max.)
111P
1hp @ 120VAC (16 Amps max.)
General Characteristics
Operating Temperature
-40° to 55°C (-40° to 131°F)
Maximum Input Power
5 W
Wire Gauge
Solid or stranded 10 – 22 AWG
Terminal Torque
13 in.-lbs.
Standards Passed
Electrostatic Discharge (ESD)
Surge Immunity
IEC 61000-4-2, Level 2, 4kV contact, 6kV air
IEC 61000-4-5, Level 4, 4kV line-to-line and line-to-
ground
Safety Marks
cUL Listed
UL508 & C22.2 No. 14
Dimensions
2.90” H x 5.26” W x 2.93” D
Weight
14 oz.
Mounting Methods
#8 screws
*use part number 233P-UCTD8
