Jupiter
6408 216th Street SW | Mountlake Terrace, WA 98043 USA
T +1.425.778.7728 F +1.425.778.7727 | www.symetrix.co
Architects and Engineers Specifications
The device shall provide twelve, eight or four inputs (Jupiter 12, 8 or 4
respectively) that are selectable as line or mic level with phantom power
and four, eight or four (Jupiter 12, 8 or 4 respectively) line level outputs.
All signal processing, mixing and routing functions (including input
gains) shall be controllable via software. Audio inputs and outputs shall
beaccessedviarearpanel3.81mmterminalblockconnectors.
The Graphical User Interface (GUI) software shall be installer
programmableusingtheWindows®XPorhigheroperatingsystem.
Computer connection and control shall be via the device’s rear panel
Ethernet connector. The GUI shall provide the management of apps,
device files and display and control of all signal processing and
configuration functions including, but not limited to: Input and Output
Gain•HighpassFiltering•LowpassFiltering•FIRFilters•Crossovers
•ParametricEqualization•GraphicEqualization•Expansion•
De-Essing•Compression•Limiting•AutomaticGainControl•
AmbientNoiseCompensation•FeedbackElimination•Automatic
Mixing•PriorityMixing•SignalRouting•Delay•Polarity.
The front panel shall include input and output signal level indicators as
well as indicators for POWER, NETWORK, and ARC.
External control shall include preset selection as well as I/O level
control and muting, and shall be via industry-standard CAT5 cable with
RJ45 connectors using the optional ARC wall panel remote controls.
All program memory shall be non-volatile and provide program security
should power fail. The device shall provide an on board real time clock
to facilitate automatic, timed changing of presets. Third-party control
systems may interface over IP using a published ASCII control protocol.
Audio conversion shall be 24-bit, 48 kHz. The dynamic range of the
processorshallnotbelowerthan110dBA-weighted.
The device shall have a captive power input socket for an external 24
VDCsupply.ThedeviceshallmeetUL/CSAandCEsafetyrequirements
and comply with CE and FCC Part 15 emissions limits. The device shall
be RoHS compliant. The chassis shall be constructed of cold rolled
steel and moulded plastic, and mount into a standard 19” 1U EIA rack.
The device shall be a Symetrix Jupiter model 4, 8 or 12.
Declaration of Conformity
We, Symetrix Incorporated, 6408 216th St. SW,
MountlakeTerrace,Washington,USA,declareunderour
sole responsibility that the product:
Jupiter•4, Jupiter•8, and Jupiter•12
to which this declaration relates, is in conformity with the
following standards:
UL 60065, cUL 60065, IEC 60065, EN 55103-1, EN
55103-2, FCC Part 15
The technical construction file is maintained at:
Symetrix, Inc.
6408 216th St. SW
MountlakeTerrace,WA,98043USA
The authorized representative located within the European
Community is:
World Marketing Associates
P.O.Box100
St.Austell,Cornwall,PL266YU,U.K.
Date of issue: April 26, 2010
Placeofissue:MountlakeTerrace,Washington,USA
Authorized signature:
DaneButcher,President,Symetrix Incorporated.
A&ESpecications•DeclarationofConformity
