Performance Data
Performance Data
ITEM DESCRIPTION DETAILS
INPUTS
Number of Inputs Twelve (12), eight (8), or four (4) switchable balanced mic
or line level on Jupiter 12, 8 or 4 respectively.
Connectors
3.81mmterminalblocks.
Nominal Input Level +4dBulineor-36dBumiclevel(softwareselectable)
with20dBofheadroom.
NOTE: For unbalanced analog input, either reference the minus
input terminal to the signal source ground (preferred) or ground
the minus input to the adjacent ground terminal (tie low to
ground). Using the second method deprives you of the common
mode rejection inherent in a balanced input, even when coming
from an unbalanced source.
Mic Pre-amp Gain
+40dB.
Input Trim +/-24dB.
Maximum Input Level +23dBu
Input Impedance > 18 kΩ balanced, > 9 kΩ unbalanced,
> 2 kΩ with phantom power engaged.
CMRR
>50dB@1kHz,unitygain
Mic Pre-amp EIN <-125dBu,22Hz-22kHz,100Ωsourceimpedance.
Phantom Power +20 VDC, 20 mA maximum per input.
OUTPUTS
Number of Outputs Four (4), eight (8), or four (4) line level on Jupiter 12, 8 or
4 respectively.
Connectors
3.81mmterminalblocks.
Nominal Output Level +4dBulinelevelwith20dBofheadroom. NOTE: For unbalanced analog output, do not connect the minus
outputterminal.Unbalancedconfigurationresultsin6dBlower
output level.
Maximum Output Level
+24dBu.
Output Impedance 200 Ω balanced, 100 Ω Unbalanced.
SYSTEM
Sampling Rate 48 kHz.
Frequency Response
20Hz-20kHz,+/-0.5dB.
Dynamic Range >110dB(A-Weighted),inputtooutput.
THD+Noise <-85dB(un-weighted);1kHz@+22dBuwith0dBgain.
Interchannel Crosstalk <-90dB@1kHz,typical.
Latency < 1.6 ms, input to output with all DSP inactive.
