Symmetricom ATS-6511C User Manual

DOC 6511_Release K
ATS-6511A/B/C Users Guide
62
1 MHz -150 dBc/Hz -150 dBc/Hz
10 MHz Module (4395B-10)
This module provides four 10 MHz outputs. The module also monitors each output for levels
below approximately 10 dBm, after which an alarm is raised.
Characteristic Description
Number of outputs Four
Output connectors BNC(F)
Impedance 50 Ω
Amplitude +13dbm +/- 2dBm
Signal Sine Wave
Harmonics < -40dBc
Phase Noise ATS 6511C
0.1Hz -80 dBc/Hz
1 Hz -110 dBc/Hz
10 Hz -132 dBc/Hz
100 Hz -136 dBc/Hz
1 kHz -141 dBc/Hz
10 kHz -141 dBc/Hz
100 kHz -155 dBc/Hz
1 MHz -155 dBc/Hz
5 MHz Module (4395A-5)
This module provides four 5 MHz outputs. The module also monitors each output for levels below
approximately 10 dBm, after which an alarm is raised.
Characteristic Description
Number of outputs Four
Output connectors BNC(F)
Impedance 50 Ω
Amplitude +13 dbm ± 2 dBm
Signal Sine Wave
Harmonic < -40dBc
Phase Noise (dBc/Hz)
ATS 6511A/B ATS 6511C
1 Hz -106 dBc/Hz -116 dBc/Hz
10 Hz -131 dBc/Hz -138 dBc/Hz
100 Hz -138 dBc/Hz -140 dBc/Hz
1 kHz -144 dBc/Hz -144 dBc/Hz
10 kHz -146 dBc/Hz -146 dBc/Hz
100 kHz -146 dBc/Hz -146 dBc/Hz
1 MHz -146 dBc/Hz -146 dBc/Hz
