ATS-6511A/B/C Users Guide
63
5 MHz Module (4395B-5)
This module provides four 5 MHz outputs. The module also monitors each output for levels
below approximately 10 dBm, after which an alarm is raised.
Characteristic Description
Number of outputs Four
Output connectors BNC(F)
Impedance 50 Ω
Amplitude +13 dBm +/- 2 dBm
Signal Sine Wave
Harmonic < -40 dBc
Phase Noise ATS 6511C
0.1Hz -86 dBc/Hz
1 Hz -116 dBc/Hz
10 Hz -138 dBc/Hz
100 Hz -142 dBc/Hz
1 kHz -146 dBc/Hz
10 kHz -146 dBc/Hz
100 kHz -157 dBc/Hz
1Mhz -157 dBc/Hz
1 MHz Module (4395A-1)
This module provides four 1 MHz outputs. The module also monitors each output for levels below
approximately 10 dBm, after which an alarm is raised.
Characteristic Description
Number of outputs Four
Output connectors BNC(F)
Impedance 50 Ω
Amplitude +13dbm +/- 2dBm
Signal Sine Wave
Harmonics < -40dBc
Phase Noise
ATS 6511A/B ATS 6511C
1 Hz -120 dBc/Hz -130 dBc/Hz
10 Hz -145 dBc/Hz -145 dBc/Hz
100 Hz -152 dBc/Hz -154 dBc/Hz
1 kHz -158 dBc/Hz -158 dBc/Hz
10 kHz -160 dBc/Hz -160 dBc/Hz
100 kHz -160 dBc/Hz -160 dBc/Hz
