Symmons H321-V - Parts Breakdown and Tools; Replacement Parts Identification; Required Installation Tools; Installation Notes

Symmons Industries, Inc. ■ 31 Brooks Drive ■ Braintree, MA 02184 ■ Phone: (800) 796-6667 ■ Fax: (800) 961-9621
Copyright © 2018 Symmons Industries, Inc. ■ symmons.com ■ gethelp@symmons.com ■ ZV-2574 REV B ■ 102618
Replacement Parts
Item Description Part Number
A
B
C
D
(2x) Cap
(2x) Screw
(2x) Bar End
(2x) Tile Anchor
RA-003
E
30" Bar
48" Bar
RA-005
RA-006
F Hand Shower EF-100
G 60" Hose EF-02976
H Wall Elbow EF-105
I Slide Assembly RA-004
G
H
A
B
C
D
E
A
B
C
D
I
F
Notes:
1) Apply a bead of silicone around the perimeter of all shower trim
installed ush to the nished wall.
2) Apply plumber tape to all threaded connections.
Parts Breakdown
Tools Required for Installation
Adjustable Wrench
Drill
Phillips Head
Screwdriver
Plumber Tape
Silicone
