SYNAPTICON SOMANET Node 400 Documentation

1.3.3.6.2 EtherCAT OUT Port
Pin Name Function
1 * TX+ Differential transmit pair, positive
line
2 TX- Differential transmit pair, negative
line
3 Shield
4 RX+ Differential receive pair, positive
line
5 RX- Differential receive pair, negative
line
* Pin 1 is on left
* Pin 1 is on left
1.3.3.7 Connector types and mating parts numbers
Connector
description
Manufacturer Item
Number
Mating part Crimping
Contact
Cable
Analog IN JST Sales America
Inc.
SM12B-
GHS-TB
GHR-12V-S SSHL-002T-
P0.2
26-30
AWG*
Encoder Ports 1 &
2
TE Connectivity 1-338068-0 1-215083-0
(remove
latch!)
N/A Flat Cable
28 AWG
P1.27
Port 3 (Digital IO) JST Sales America
Inc.
SM08B-
GHS-TB
GHR-08V-S SSHL-002T-
P0.2
26-30
AWG*
Power Terminal
Block
Phoenix Contact 1935831 N/A 5859
WH005
(Alpha
Wire)
EtherCAT IN/OUT Molex 53261-0571 510210500
**
500588000 28-32
AWG
* Crimped cable from JST Sales America can be used, Parts number: AGHGH28K305
** Housing only. Complete cable assemblies in various lenght also available, for example 151340501
(50 mm)
Hardware Manuals / SOMANET Node / SOMANET Node rev.
D.3/D.4
© 2020 Synapticon GmbH | Daimlerstraße 26 | D-71101 Schönaich Documentation v 4.2.0 | Build: 2020-10-02 19/27
