Syncrolite Profile 3 Series - Scroll Installation

ScrollInstallation

1.FindthetagonthescrollandlocatethefastenersintheFIXEDrollertubetouseasyour
guide.Placethescrollendontherollermakingsurethatthescrolldoesnottoucheitherside,
thetagfacesupandwillrunthroughthesensorwhenrolledthroughasshownbelow.


Scroll should attach to fixed
side with tag facing up

2.Using(2)3”piecesofgeltape,attachthescrolltothefixedroller.

3.Pullthebeltandrollthescrollontotherollertowhichitwasjusttaped.Takethelooseend
andthreaditthroughtheguidesandthenthesensor.

4.Makesurethatthereisnoslackinthegelandholdittightl
yinplacewhileyoufindthe
fastenersintheSPRINGrollertube.Turnthecolorchangershellwiththesensorawayfromyou
androllthespringrollerbackwardfourtimesto“load”it.
