Specifications
Parameter Min Typ Max
Supply voltage (DC)
LV-DC
(AC)
17
10
110
24 30
16
240
Input sensitivity (mV/V)
High sensitivity (HS) version
0.25
0.125
4.4
2.2
Excitation voltage (V)
LV-DC
9.95 10
6
10.05
Bandwidth (-3dB)
2 pole low pass filters
Filtered Versions
5, 25, 50 or
100Hz
1.5kHz
unfiltered version
Current consumption (mA)
(Voltage version) inc. 350 Ω
inc. 350Ω Bridge 50mA (1.17W)
Current consumption (mA)
(Current version)
“ 68 mA (1.6W)
Current Consumption (mA)
(Low voltage -DC version)
“ 31mA (1.2W)
Full scale step response (msec) 0.41
Zero temperature drift at output
(ppm/C)
20
Span temperature drift (ppm/C) 15
Non Linearity 0.002%
Zero adjustment (V)
(Voltage version)
-4 4
Zero adjustment (mA)
(Current version)
1 14
Span fine adjustment -20% 20%
Output load Voltage version (mA) -8 8
Output load Current version (Ω) 0 650
Operating temp. 1x350Ω cell 24V
(°C)
-20 100
Operating temp. 4x350Ω cell 24V
(°C)
-20 65
Storage temperature (°C) -65 125
EMC Tested to BS EN 61000-4-21:2011
Case H (on rail) = 72.5mm, W = 18mm, D = 62mm.
Moulded in grey flame resistant polyamide.
For use with rails to EN50035 (DIN46277-1)
asymmetric or
EN50022 (DIN46277-3) symmetric.
Connections Rising Clamp terminals with 3.5 x 2.5mm apertures
