Synology RT2600ac User Manual

4
Chapter 1: Meet Your Synology Router
Synology Router at a Glance
No. Article Name Location Description
1
Antenna Base
Rear Panel
Install the included antennas here.
2
Power Button Press to power on/off the Synology Router.
3
Power Port Connect the AC power adapter here.
4
RESET Button
Press and hold for four seconds (Soft Reset) or for ten seconds (Hard
Reset).
5
USB 2.0 Port
Connect an external drive, USB printer, or other types of USB devices
here.
6
WAN Port
Connect a network cable from the ISP modem into this port to establish
WAN connection.
7
LAN Port Connect network cables into these ports to establish LAN connection.
8
SD Card Slot
Front Panel
Insert the SD card here.
9
STATUS Indicator Displays the status of the system.
10
2.4G Wi-Fi Indicator Displays the status of 2.4G Wi-Fi connection.
11
5G Wi-Fi Indicator Displays the status of 5G Wi-Fi connection.
12
WAN Indicator Displays the status of WAN connection.
13
LAN Indicator Displays the status of LAN connection.
14
USB 3.0 Port
Left Panel
Connect an external drive, USB printer, or other types of USB devices
here.
15
Eject Button
1. Press to eject USB/SD external storages.
2. Displays the status of USB/SD external storages.
16
WPS Button
Right Panel
Press to start WPS.
17
Wi-Fi Switch Switch to turn on/off the Wi-Fi network.
Note:
For LED indicator information, please refer to "Appendix B: LED Indicator Table".

Synology RT2600ac Specifications

General

Certification	RoHS, CE, FCC, NCC, RCM
Processor cores	2
Built-in processor	Yes
Processor frequency	1700 MHz
Antennas quantity	4
Antenna gain level (max)	4.5 dBi
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible memory cards	SD, SDHC, SDXC
Ethernet LAN (RJ-45) ports	5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Product type	Tabletop router
Product color	Black
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Operating altitude	0 - 5000 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
VPN support	PPTP, OpenVPNTM, L2TP IPSec
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	1733 Mbit/s
WLAN data transfer rate (first band)	800 Mbit/s
SIM card slot	No
Firewall security	IPv4, IPv6
Security algorithms	WEP, WPA, WPA2, WPS
Supported network protocols	IPv4, IPv6, FTP, FTP SSL / TLS, SFTP
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Cables included	LAN (RJ-45)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	169 mm
Width	280 mm
Height	77 mm
Weight	700 g
