Tools and Parts for Drive Installation
• A screwdriver
• At least one 3.5” or 2.5” SATA drive (please visit
www.synology.com
for compatible drive models)
Warning:
If you install a drive that contains data, the system will format the drive and erase all existing data. Please
back up any important data before installation.
Install Drives
1
Pull the drive tray handle in the direction as indicated below to remove the drive tray.
2
Load drives in the drive trays.
•
For 3.5” drives:
Place the drive in the drive tray. Turn the tray upside down and tighten screws into the four
spots indicated below to secure the drive.
•
For 2.5” drives:
Place the drive in the drive tray. Turn the tray upside down and tighten screws into the four
spots indicated below to secure the drive.
Hardware Setup
2
Chapter
6
