Synthes TRS - Power Tool Components; Handpiece and Lid Details; Power Module Description

2
3
1
4
45
1
2
3
6
6
6
6
45
1
2
3
Handpiece (05.001.201/05.001.240)
1 Trigger(s)
2 Lid
3 Mode switch (integrated onto lid)
General Information on Power Tools
Power module (05.001.202)
1 Information button (when pressed, the charge status
display and / or service indicator illuminate for a few
seconds)
2 Charge status display
3 Service indicator (when LED illuminates the power module
must immediately be sent to the nearest Synthes service
center)
4 Lever to remove the power module from the handpiece
Trauma Recon System Instructions for Use Synthes 5
Lid (05.001.231/05.001.241)
4 UNLOCK position
5 LOCK position
6 Mode(s) for dedicated applications
