Syscall Nttworks GP-100R - Product Composition and Specifications; System Installation Guide

< Transmitter GP-1000T SET >
ManualAntenna
Adapter
(DC 12V 1A)
Transmitter
(GP-1000T)
< Guest pager SET >
Charger Jump Cable
(Optional purchase)
Adapter
(AC 8V 3A)
Guest pager
4) Twist the antenna onto the connector located on the rear of the transmitter.
5) Plug-in the adapter and insert the connector into the ports next to the antenna.
6) Setting group & channel numbers to start using the system. (refer to 4-2., page4)
2. Installation
* Charging time : About 2.5 hours
* Standby time : About 9 hours
* Capacity of adapter : Recharging up to 20 guest pagers at once.
1. Composition & Specications
1) Stack up guest pagers on the charger. / Insert GP-200R into the charger.
2) Plug-in the adapter and insert the connector.
3) Make sure all pagers are fully charged and powered on.
GP-1000T
SET
Guest pager
SET

GP-100R, GP-101R GP-200R GP-300R
FM / 433MHz
Dipole Antenna / 300m
DC 12V / 1A
W130 × L170 × H32mm
410g
Graphic LCD
Transmitter (GP-1000T)
Frequency
Power
Battery
Dimension
Weight
Color
FM / 433MHz
AC 8V 3A
Lithium-polymer battery
￠95 × H17mm
86g
Red, Green, Black
FM / 433MHz
AC 8V 3A
Lithium-polymer battery
W53 x L105 x H11 mm
35g
Black
FM / 433MHz
AC 8V 3A
Lithium-polymer battery
W58 x L115 x H15 mm
72.5g
White&Blue
Frequency
Antena/Distance
Power
Size
Weight
Display
