System One S Series - SPECIFICATIONS; Product Specifications; Approved Solvents; Certifications

Power Requirements: 115VAC, 60 Hz, 12A
Environment: 41°F to 104°F (5°C to 40°C)
Solvent Capacity: 30 gallons US
Figure 2
This unit is approved for use with mineral spirits with a flashpoint greater than 140° Qsol
©
brand solvents.
Contact the manufacturer for other approved solvents.
CAUTION: Avoid distilling solvents that may include unstable reactives, such as Nitrocellulose.
This unit is ETL listed and conforms to UL 2208, Standard for Solvent
Distillation Units and is certified to CAN/CSA C22.2 no.88.
4
SPECIFICATION
501S
571S
581S
591S
W (Width) Sink Basin
33”
39”
45”
54”
D (Depth) Sink Basin
27”
29”
27”
27””
OH (Operating Height)
68”
70”
68”
68””
WH (Working Height)
39”
39”
39”
39”
FS (Front Spacing)
36”
36”
36”
36”
RS (Rear Spacing)
3”
3”
3”
3”
SS (Side Spacing)
4”
4”
4”
4”
Weight (Empty)
335lb
350lb
363lb
377lb
OH
WH
SPECIFICATIONS
Product Specifications
Approved Solvents
Certifications
