Mainmenuitem
Sub-menuitem1Sub-menuitem2
Explanations
Active
Cooling
recovery
No
Statusofthecoolingrecovery
function
Externalset
point
Notactive
Statusoftheexternalsetpoint
→Alarmevents
Alarmloglistalongwiththe
timeanddatetheyoccurred
Movedownandupinthelistby
pressing↑↓
→Input/Output
→AI
StatusoftheAnanlogueinputs
→DI
StatusoftheDigitalinputs
→UI
StatusofUniversalAnalogue
inputsorUniversalDigital
inputs.
→AO
StatusoftheAnalogueoutputs
→DO
StatusoftheDigitaloutputs
→Temperature
Extractair
temp
Act.:ºC
Setp:18.0ºC
Conguredtemperaturecontrol
(DefaultisExtractair
temp)
Actualtemperatureinthe
chosencontrolmode
Temperatureforthechosen
controlmode
Ifcascade
control
Max/minsupply
setp.
Max:30ºC
Min:12.0ºC
Setthemaximumandminimum
allowedsupplyairtemperature
incaseofcascadecontrol
Logontoservicelevelneeded
tochangesettings
Outdoortemp:
ºC
Supplyairtemp
Actual:ºC
Setp:18ºC
Actualoutdoorairtemperature
Actualsupplyairtemperature
Calculatedsupplyairsetpoint.
Theexhaustaircontroller
outputsignalgeneratesthe
supplyaircontroller’ssetpoint
value.
Frost
protection
Actual:ºC
Actualwatertemperatureinthe
waterheatingbattery.(Only
visibleforHWunits)
Exhaustair
temp
Actual:ºC
Actualexhaustairtemperature.
→Timesettings
→Time/Date
Setcorrecttimeanddate.
TA450-4500
OperationandMaintenanceInstructions
132616
13
SystemairSverigeAB
