3.6.2ConnectionboxTA650-2000EL
Fig.3ConnectionboxTA650-2000EL
A
Speedtransformer
B
ControlunitCorrigo
C24VTransformer
DTerminalblock
E
Terminalblockforpowerinput
F
Resetbuttonforoverheatprotection
GCircuitbreaker
TA450-4500
OperationandMaintenanceInstructions
132616
5
