6
10-12mm
A(mm) B(mm)
230
300
126
197
≥20
46
146
Φ75New air
supply orifice
Φ32Drain pipe outer diameter
Install the hanger
Panel
Ceiling
Main body
Hexagon nut
(Adjust to balance)
Drain pipe
Main body of the unit
Ceiling
Indoor unit model
≤ 8000 W
≥ 9000 W
NOTE
All illustrations in this manual are for reference only. They may be slightly different from the air conditioner you purchased
(depending on the model). Refer to the actual shape.
Fig. 4-7
Fig. 4-8 Fig. 4-9
Fig. 4-10
Fig. 4-11
Table: 4-2
(Unit: mm)
