Systembuild Evolution 7532296COM - Step 7: Attaching Top Panel; Attaching A to Sub-assembly

STEP 7
13
Tube
You
7.1 Attach (A) to sub-assembly B/C/D/F from previous step with (1) as illustrated.
7.2 Use (13) to cover cam lock hole as illustrated.
Proper orientation of CAM LOCK
Tip
Quick
Assembly
UNLOCK
LOCK
systembuild.com
×4
1
13
×4
A
B
C
D
F
1
13
