Systembuild Evolution 7532296COM - Step 10: Attaching Doors; Mounting Doors J

STEP 10
16
Tube
You
10.1 Attach (J) to sub-assembly A/B/C/F from previous step with (11) as illustrated.
10.2 Attach (7) to (J) with (5) as illustrated.
10.3 Attach (15) to (J) with (4) as illustrated.
