[CLIP] | Lights under the following conditions:
n Channel overload. The built-in limiter ist activated.
Reduce in this case the volume until the LED goes out and the built-in limiter is deactivated.
n Output short circuit.
Turn o the device immediately, correct the short circuit and turn on the device again.
[SGL] | Indicates the presence of an input signal.
[PRO] | Lights under the following conditions:
n Three to ve seconds after switching on or o when the device is in an unstable condition.
n The temperature of the amplier blocks has reached 85°C.
n One or more protection circuits have been triggered, or the device is faulty.
[STR] | Lights when the device is operated in stereo mode.
[PAR] | Lights when the device is operated in parallel mode.
[BRI] | Lights when the device is operated in bridged mode.
Connections and controls
Proline 3000
17
Power Amplier
