TabTimer Careousel MK3/11 - Page 3

3
INTRODUCTION
The TabTimer® Careousel MK3/11 ® Automac Pill Dispenser reminds the user by means of an
alarm and ashing light when to take their medicine. It will make the correct dose available at
the correct me of day or night, whilst keeping other pills locked out of sight. Medicine is
dispensed from an internal tray containing 29 secons. Maximum number of daily alarm
sengs - 28.
When the alarm sounds the internal tray will rotate one posion. The correct dosage will
come into view in the lid opening. Pills should be removed from the dispenser by lng it and
pouring the pills into the hand or suitable container. This will also cancel the alarm signal and
the ashing light.
Technical data:
Dimensions - length 190mm, width 180mm, height 56mm
Weight - 380g excl. baeries, 480g incl. baeries
Compartment volume - approx. 10ml per compartment
Power supply - 6V (4 x 1.5V Alkaline baeries)
Baery life - up to 1 year
Open the lid as illustrated. Place an index
nger in the lid opening and press in the
catch with a thumb. Li the lid.
The key and baery case securing screw
can be found in one of the pill
compartments.
Open the lid to the baery box
(underneath the dispenser) and
acvate the dispenser by removing the
baery isolang strip. (Note the correct
baery polarity + / - )
USING THE DISPENSER FOR THE FIRST TIME
Figure 2.
Figure 3.
