Tadano GR-800EX - Dimension and Axle Weight Distribution; Crane Dimensions; Axle Weight Distribution Chart

DIMENSION
- 15 -
Basic standard machine includes:
5-section boom (12.0 m - 47.0 m)
2-stage jib (10.1 m, 17.7 m)
Mitsubishi 6M60-TL
29.5-25 34PR tires
Single top
6.6 ton hook block
Add:
1. 80t 7 sheaves hook block
 2. 50t 5 sheaves hook block
3. 35t 3 sheaves hook block
Remove:
1. 6.6 ton hook block
2. Top jib
3. Base jib
4. Counter weight with auxiliary winch and wire rope
GVW Front Rear
Axle Weight Distribution Chart Unit : kg
SPEC. SHEET NO. GR-800E-2-00102/EX-04
Note: Dimension is with boom angle at -1.5 degree.
51,410
+700
+500
+450
-165
-335
-865
-9,980
24,325
+1,350
+960
+870
-235
-450
-1,705
+4,240
27,085
-650
-460
-420
+70
+115
+840
-14,220
2,502
3,315
8,020 3,950
8,390
3,550 3,780
1,875
2,200
4,190
12,000 ~ 47,000
3,795
2,700 5,500 6,700 7,300
445
12.2˚
15.0˚
14,375
2,405
