tado° – Technical Documentation V1.0
1
Product Overview
tado° Smart Thermostat tado° Extension Kit
• Measures temperature, humidity & luminosity.
• Displays the measured temperature and allows
adjusting operation and set point.
• Controls heating when wired to the heating
system
• Acts as a sensor and remote control when
installed in combination with the Extension Box
(depends on the existing heating setup).
• Required for the replacement of hot water
controlling programmers (UK only).
• Recommended for heating system setups
without a room thermostat (the Extension Box
acts as a reciever; the Smart Thermostat as a
wireless sensor and remote control.
• Controls heating based on sensor data from
the tado° Smart Thermostat.
• Typically installed next to the boiler or as a
replacement for an existing external control-
ler.
• Compatible with the UK standard backplate.
1
2
tado° Smart Thermostat tado° Extension Box
tado° Bridge Power adapter
USB cable
Labels Labels 4-wire cable Euroblock-2 plug RAST5-2 plug
Screw Terminal
Screw-driver Sticky pads
Screws Screwswall plugs wall plugs
Housing screw
AAA Batteries
Insulating caps
Ethernet cable
tado° Bridge and its accessories tado° Extension Kit accessories Installation accessories
link
router
internet
