18
Child Seat with Bar Assembly
This step requires the Accessory Bar, which can be ordered separately
NOTE
Step 1: Assembling the seat anchor
1. Insert the anchor on the bar’s metal tube as shown
FIG 32
. Position the
second part of the anchor on the opposite side and fasten the two parts
together using the three screws provided
FIG 32
.
Step 2: Installing the seat
1. Insert the anchor into the slot in the seat’s backrest by sliding the seat onto
the anchor as shown
FIG 32
2. Pull the internal latch located on the underside of the seat bottom, attach the
rear part of the seat to the frame and release the latch
FIG 33
. The two rear
bolts will lock into position and you will hear a “click”
3. Pull the external latch located on the underside of the seat bottom, secure
the front part of the seat bottom to the frame as shown and release the latch
FIG 33
. The two front bolts will lock into position and you will hear a “click”
4. Test the Child Seat to ensure it is firmly fixed to the Cargo Compartment
Storing cargo in Taga 2.0
Taga 2.0 offers you the option of storing and locking your items inside the
Cargo Compartment
To close the Cargo Compartment, simply fold the two Child Seats as described
in the section labelled “Child Seat Folding” and in
FIG 34
.
The two Child Seats can be locked to each other using Taga’s special lock,
which can be ordered separately
Folding the seats can be achieved even if the Accessory Bar remains in place,
assuming it is positioned in the center
Once closed, the back of the seats can be used as a loading surface for larger
items, but please ensure that you secure the luggage or box with bungee
cords
FIG 34
. The bungee cords can be ordered separately.
If you don’t have child seats and would like to lock your Cargo Compartment,
please check Taga’s website or contact our support team
