17
When returning the Child Seat back to its upright position, there is a
stopper on the rail which prevents the seat from folding unintentionally.
Do not attempt to push the seat beyond the stopper as it may damage
the seat mechanism.
CAUTION
Child Seat Folding
To fold the seat, pull the internal latch located on the underside of the Child Seat
bottom, push the backrest forwards and simultaneously push the seat backwards
FIG 29
. Pull the harness out of the way of the folding seat, so it does not get
squashed between the seat bottom and the backrest. When folding the seat push
the backrest down until you hear a “click” – to lock in place.
Leaving the harness squashed between the seat and backrest in folded
position may leave marks on the padding and will prevent the seats from
folding fully.
FIG 29
CAUTION
Two Child Seats Assembly
If you have two child seats, you can position them facing each other, facing
forwards or facing backwards. In order to have them positioned in the same
direction you will require the Accessory Bar, which can be ordered separately.
FIG 30
The position of the bar can be adjusted to allow more space for the
legs of the older child.
FIG 30
NOTE
Do not recline the front seat.
Do not place your child in the front seat when there is no child in the rear
seat (closer to the parent) as this may result in the front of the bike tipping
forwards when the rider dismounts.
FIG 31
!
WARNING
