10 Technical Specification
XT-1 XT Mini
Operating frequencies XT-1 eu: 865.6-867.6 MHz
XT-1 us: 902-928 MHz
XT Mini eu: 865.6-867.6 MHz
XT Mini us: 902-928 MHz
Read range Up to 8 m (26 ft) Up to 5 m (16 ft)
Dimensions 300x300x60 mm (11.8x11.8x2.4 in) 261x152x55 mm (10.3x6.0x2.2 in)
Weight 2.3 kg (5.1 lbs) 0.8 kg (1.8 lbs)
Housing Aluminium housing
UL94 certified XENOY™ cover
UL94 certified plastic XENOY™
Part No. XT-1 eu: 152500
XT-1 us: 152600
XT Mini eu: 152300
XT Mini us: 152400
Output power XT-1 eu: 2W (e.r.p.)
XT-1 us: 4W (e.i.r.p.)
< 500 mW (e.r.p)
FCC ID M39XTXX M39XTMX
Power consumption 10W (max 12W) 4W (max 5W)
Ingress protection IP 66
Operating temperature -40°C to +60°C (-40°F to +140° F)
EN 60068-2-1 Ad, EN 60068-2-2 Bd, EN 60068-2-14 Nb
Storage temperature -40°C to +85°C (-40°F to +185°F)
Power supply 12-24 VDC supply
Inputs 3 isolated inputs
Outputs 3 isolated outputs shared with Wiegand/Magstripe
Relay 1 relay output 60VDC, 2A
Interfaces RS232, RS485, Wiegand/Magstripe, Ethernet (2 ports on XT-1),
USB service Interface, Tamper switches (XT Mini only)
Certificates CE Certificate according to R&TTE-directive 1999/5/EC and FCC
RoHS Directive 2002/95/EC and 2011/65/EU
WEEE 2002/96/EC
Standards EPC Gen 2 (ISO 18000-63)
EMC EN 301489-1, EN 301489-3
Radio EN 302 208-1, EN 302 208-2
FCC: CFR 47, Part 15 subpart C
Safety & health EN 60950-1, EN 60950-22 & 1999/519/EC
Mechanical EN 60068-2-27 Ea, EN 60068-2-64 Fh
Manuals and documentation XT-1/XT Mini Manual, 13-111
TAGP Manual, 05-172
Accessories Universal Mounting Kit: 193600
ISOcard ID-tag: 225000
WindShield ID-tag: 221000
Communication protocols TAGP, OSDP, and various OEM protocols
