8.1.18
M2000-00
31/10/96 Copyright TEL
T2008 Mechanical & Miscellaneous Parts
IPN Description IPN Description
065-00010-20 BEAD FERRITE BALUN 4B1 PHILIPS
200-00010-03 WIRE T/C 0.9MM
201-00030-02 WIRE #1 T/C WIRE 7/0.2MM PVC RED
LED WIRING-330MM
201-00030-04 WIRE #1 T/C WIRE 7/0.2MM PVC YELLOW
INTERNAL SPEAKER LINK (REFER TO WIRING DIAG.)
201-00030-05 WIRE #1 T/C WIRE 7/0.2MM PVC GREEN
C8 & C9 WIRING TO HEATSINK
201-00030-10 WIRE #1 T/C WIRE 7/0.2MM PVC BLACK
201-00030-10 WIRE #1 T/C WIRE 7/0.2MM PVC BLACK
LED WIRING - 330MM, MIC CLIP - 300MM.
205-00010-03 CABLE TWIN CYCLE FLEX 2/7/0.2MM BLACK
205-00010-06 CABLE TWIN AUTO 153 2/28/0.3 RED & BLACK
220-01170-03 PCB T508-21
232-00010-21 SWITCH PUSH SPST MAINS ON/OFF
240-00026-19 PLUG HOUSING 7-POS CONN 172495-1
240-00026-20 PLUG RECEPTL 7-POS CONN 172773-1
240-02010-75 SKT RECEPTL T2000 172775-1
240-04021-63 CONN 2WAY 24AWG (BLACK) INLINE HRMAPHR.
252-00010-02 CLIP MIC MTG
265-00010-07 FUSE 10A CARTRIDGE 6*32MM BS4265
302-05220-00 (L) BRKT HEAT TRANSFER T508/T2008
303-03031-00 CASE 1 PR TOP/BTTM PLASTIC COMPL
308-13064-01 HSINK A1M1755 DCAST T508/2008
316-06442-00 PNL FRT A3A697 COMPL T2008 PWR SUPPLY
319-30055-00 SPACER A4M2615 MIC MTG T2008
340-00010-06 FUSE CLIP PCB MTG 6.3MM CARTRIDGE FUSE
340-00011-52 COVER INSULATING FUSEHLDR PCB MTD
345-00040-08 SCREW M3*12MM PAN POZI ST BZ
Q1 MOUNTING AND PCB TO HEATSINK
349-00010-28 SCREW NO6X1/2 PAN POZI TYPE 25
349-00010-33 SCREW SLFTAP NO 6*3/4IN TYPE AB PAN PZI BZ
FOR WALL MOUNTING
349-00010-40 SCREW SELFTAP NO 8X3/8IN AB PAN SLOT BZ
349-00010-40 SCREW SELFTAP NO 8X3/8IN AB PAN SLOT BZ
349-00020-30 SCREW TAPTITE M3X6MM PAN PZI BZ EARTH
PCB TO HEATSINK MOUNTING X 2
349-00020-31 SCREW TAPTITE M3X10MM PAN POZI BZ
349-00020-45 SCREW TAPTITE M4X20MM PAN POZI BZ
BRIDGE RECTIFIER MOUNTING
352-00010-08 NUT M3 COLD FORM HEX ST BZ
Q1 MOUNTING
353-00010-10 WASHER M3 FLAT 7MM*0.6MM ST BZ
353-00010-12 WASHER M3 SPRING BZ Q1 MOUNTING
353-00010-24 WASHER M4 FLAT ST BZ A4M1957
353-00010-24 WASHER M4 FLAT ST BZ A4M1957
BRIDGE RECTIFIER MOUNTING
356-00010-04 TAG SOLDER 3MM HEAVY DUTY EARTH MAINS
EARTH TAG TO HEATSINK
356-00010-05 TAG SOLDER 4MM LONG M6144/4.2
362-00010-09 GASKET SIL INSULATING TO-3
Q1
365-00011-54 LABEL WHITE RW1556/2 90*24MM SPECIAL ADHESV
365-00100-03 LABEL BLANK 10.8X30MM S/A METLSD POLYES
365-00100-04 LABEL BLANK 30X6.7MM S/A METALLISED POLYES
365-00100-07 LABEL BLANK 47X30MM S/A METLSD POLYES
365-00100-20 LABEL WHITE S/A 28X11MM QUIKSTIK RW718/4
365-01372-00 LABEL POWER CORD CODE/WARNING
369-00010-05 FOOT PLASTIC 10MM SQ SELF ADHESIVE BLACK
369-00010-14 TIE CABLE NYLON 100*2.6MM
369-00020-25 SPONGE RUBBER 3/8 INCH SQ SKELLERUP S3
TOP CASE 2 X 56MM
369-00020-45 TAPE AL FOIL S/A 3M NO 425
399-00010-10 RUBBER BAND NO 33
MAINS PLUG
399-00010-51 BAG PLASTIC 75*100MM
399-00010-59 BAG PLASTIC 225*300MM
400-00010-30 SLEEVING 3MM PVC
2X 3.5MM
400-00010-30 SLEEVING 3MM PVC
2X5MM OVER M3X12MM PAN POZI SCREWS.
400-00020-03 SLEEVING 1MM SIL RUBBER
D1 WIRING
400-00020-05 SLEEVING 1.5MM SIL RUBBER LED WIRES, Q1
409-20008-01 USER GUIDE T2008 PWR SUPPLY
410-00010-36 PKG POLY FOAM 2 PCS T508 A1M1860
410-01038-01 PKG SLEEVE CARD T2008 KIWI P.O.
410-01087-00 CRTN T508/T2008PS OUTER (5 X UNITS)
T2008-21 VARIANT PARTS
240-00010-18 PLUG 3 PIN MLDED ON 2.4M 0.75MM2 230V MAINS
NEW ZEALAND MAINS SUPPLY PLUG (T2008-21)
T2008-22 VARIANT PARTS
240-00010-19 PLUG US 3PIN MOULDED ON 2.4M FLEX 120V 10A
USA MAINS SUPPLY PLUG (T2008-22)
T2008-23 VARIANT PARTS
240-00010-22 PLUG MLDED 3PIN ON 2.0M 5AMP 240V MAINS UK
MAINS SUPPLY PLUG (T2008-23)
T2008-24 VARIANT PARTS
240-00010-20 (L) PLUG EURO SAFETY PLUG WITH 2.5M CABLE
EUROPEAN MAINS SUPPLY PLUG (T2008-24)
