T2000-A450X Parts List (IPN 220-01335-04)

Ref Var IPN Description Ref Var IPN Description

8.10.5

T2000-A450X CTCSS & Scrambler Kit

M2000-00

31/12/97 Copyright TEL

8.10.4 PCB Information

#4500 CTCSS 038-10000-00 RES 0603 CHIP ZERO OHM 1/16W +

#2T502 SCRAM 038-10000-00 RES 0603 CHIP ZERO OHM 1/16W +

C1 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V

C2 018-12330-10 CAP 0603 CHIP 33P 50V NPO +-1%

C3 018-12150-10 CAP 0603 CHIP 15P 50V NPO +-1%

C6 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V

#C11 CTCSS 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V

#C11 SCRAM 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

C12 015-27100-10 CAP CER 0805 CHIP 1M +80-20% Y5V 16V

#C13 CTCSS 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C15 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C16 SCRAM 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C22 CTCSS 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

#C22 SCRAM 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

#C25 SCRAM 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

#C30 CTCSS 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

D1 001-10000-70 (S) DIODE SMD BAV70 DUAL SWITCH SOT-23

IC1 002-74900-40 (LSH) IC SMD TC7S04F SINGLE INV GATE SO-

IC2 002-18937-10 LSH) IC SMD Z89371-16FSC OTP DSP 44PIN Q

IC3 002-74917-30 LSH) IC SMD 74HC173D 4BIT DTYPE REGISTE

#IC4 CTCSS 002-11454-80 LSH) IC SMD MC145480DW PCM CODEC F

#IC4 SCRAM 002-11454-80 LSH) IC SMD MC145480DW PCM CODEC F

#IC5 SCRAM 002-11454-80 LSH) IC SMD MC145480DW PCM CODEC F

OPTION 240-10000-09 CONN SMD 24WAY (SKT/CAP WITH MTG LUGS

R1 038-15150-00 RES 0603 CHIP 15K 1/16W +-5%

R4 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

#R6 CTCSS 038-15470-00 RES 0603 CHIP 47K 1/16W +-5%

#R6 SCRAM 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

#R7 CTCSS 038-14330-00 RES 0603 CHIP 3K3 1/16W +-5%

#R8 SCRAM 038-11470-00 RES 0603 CHIP 4E7 1/16W +-5%

#R9 CTCSS 038-16470-00 RES 0603 CHIP 470K 1/16W +-5%

#R9 SCRAM 038-11470-00 RES 0603 CHIP 4E7 1/16W +-5%

#R10 CTCSS 038-14470-00 RES 0603 CHIP 4K7 1/16W +-5%

#R10 SCRAM 038-11470-00 RES 0603 CHIP 4E7 1/16W +-5%

#R11 CTCSS 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

#R11 SCRAM 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

R13 038-11470-00 RES 0603 CHIP 4E7 1/16W +-5%

#R15 SCRAM 038-11470-00 RES 0603 CHIP 4E7 1/16W +-5%

#R17 SCRAM 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

#R18 SCRAM 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

#R19 SCRAM 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

#R22 CTCSS 038-15150-00 RES 0603 CHIP 15K 1/16W +-5%

#R22 SCRAM 038-15150-00 RES 0603 CHIP 15K 1/16W +-5%

#R23 SCRAM 038-15150-00 RES 0603 CHIP 15K 1/16W +-5%

R30 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

R31 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

R32 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

R33 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

R34 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

R35 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

R36 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

R37 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

R38 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

R39 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

R40 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

R41 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

R42 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

R43 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

R44 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

#R50 CTCSS 038-16100-00 RES 0603 CHIP 100K 1/16W +-5%

#R50 SCRAM 038-16100-00 RES 0603 CHIP 100K 1/16W +-5%

#R51 CTCSS 038-16470-00 RES 0603 CHIP 470K 1/16W +-5%

#R51 SCRAM 038-16100-00 RES 0603 CHIP 100K 1/16W +-5%

#R53 SCRAM 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

#R54 CTCSS 038-16220-00 RES 0603 CHIP 220K 1/16W +-5%

#R55 SCRAM 038-16100-00 RES 0603 CHIP 100K 1/16W +-5%

#R56 SCRAM 038-16100-00 RES 0603 CHIP 100K 1/16W +-5%

R58 038-17100-00 RES 0603 CHIP 1M 1/16W +-5%

#R60 SCRAM 038-11470-00 RES 0603 CHIP 4E7 1/16W +-5%

XL1 274-01063-00 (L) XTAL 3.579545MHZ MINITURE CYLINDRICA

220-01298-01 (L) PCB FLEXI T3000 OPTIONS LOOM

220-01335-04 PCB T3000-4500 CTCSS OPTION BOARD

365-00011-38 LABEL STATIC WARNING YELLOW A4A315

365-00011-54 LABEL WHITE RW1556/2 90*24MM SPECIAL AD

369-00020-49 TAPE SA TESAMOLL 9*3 (25 M ROLLS)

369-00020-50 TAPE SA TESAMOLL 6*3MM (25 M ROLLS)

399-00010-86 BAG STATIC SHIELDING 127X203MM

410-01064-01 PKG HEADER CARD (NEW TAIT LOGO)

418-24500-00 FITTNG INS T2000-45 SCRAMBLER KIT

Variants:

CTCSS = CTCSS option

SCRAM = Scrambler option
