Tait T2000 II Series User Manual

M2000-00 T2000-700/-900 RF PCB 7.6.11
Copyright TEL 31/12/97
Ref Var IPN Description Ref Var IPN Description
IPN 220-01289-03
C1 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C2 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C3 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C100 015-23150-01 CAP CER 0805 CHIP 150P 5% NPO 50V
C101 015-22120-01 CAP CER 0805 CHIP 12P 5% NPO 50V
C102 015-23150-01 CAP CER 0805 CHIP 150P 5% NPO 50V
C104 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C105 015-21100-01 CAP CER 0805 CHIP 1PO +/-0.25P NPO 50V
C106 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
#C107 7XX 015-21560-01 CAP CER 0805 CHIP 5P6 +/-0.25P NPO
#C107 9XX 015-21470-01 CAP CER 0805 CHIP 4P7 +/-0.25P NPO
C108 015-23150-01 CAP CER 0805 CHIP 150P 5% NPO 50V
#C109 9XX 015-21820-01 CAP CER 0805 CHIP 8P2 +/-0.25P NPO
C110 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V
C111 015-21560-01 CAP CER 0805 CHIP 5P6 +/-0.25P NPO 50V
#C112 7XX 015-21120-01 CAP CER 0805 CHIP 1P2 +/-0.25 NPO 5
#C112 9XX 015-21150-01 CAP CER 0805 CHIP 1P5 +/-0.25P NPO
#C113 9XX 015-21820-01 CAP CER 0805 CHIP 8P2 +/-0.25P NPO
C114 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V
#C115 7XX 015-21820-01 CAP CER 0805 CHIP 8P2 +/-0.25P NPO
#C115 9XX 015-22120-01 CAP CER 0805 CHIP 12P 5% NPO 50V
#C117 7XX 015-21120-01 CAP CER 0805 CHIP 1P2 +/-0.25 NPO 5
#C117 9XX 015-21150-01 CAP CER 0805 CHIP 1P5 +/-0.25P NPO
#C118 9XX 015-21820-01 CAP CER 0805 CHIP 8P2 +/-0.25P NPO
C119 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V
#C121 7XX 015-21560-01 CAP CER 0805 CHIP 5P6 +/-0.25P NPO
#C121 9XX 015-22100-01 CAP CER 0805 CHIP 10P +/-0.5P NPO 5
#C122 7XX 015-21560-01 CAP CER 0805 CHIP 5P6 +/-0.25P NPO
#C122 9XX 015-22100-01 CAP CER 0805 CHIP 10P +/-0.5P NPO 5
C123 015-23150-01 CAP CER 0805 CHIP 150P 5% NPO 50V
C124 015-21680-01 CAP CER 0805 CHIP 6P8 +/-0.25P NPO 50V
C125 015-21330-01 CAP CER 0805 CHIP 3P3 +/-0.25P NPO 50V
C126 015-21560-01 CAP CER 0805 CHIP 5P6 +/-0.25P NPO 50V
C127 015-22120-01 CAP CER 0805 CHIP 12P 5% NPO 50V
C128 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C129 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C130 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C132 015-23150-01 CAP CER 0805 CHIP 150P 5% NPO 50V
C133 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V
C134 015-21680-01 CAP CER 0805 CHIP 6P8 +/-0.25P NPO 50V
C135 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C136 015-21680-01 CAP CER 0805 CHIP 6P8 +/-0.25P NPO 50V
C137 015-23100-01 CAP CER 0805 CHIP 100P 5% NPO 50V
C138 015-21680-01 CAP CER 0805 CHIP 6P8 +/-0.25P NPO 50V
C139 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C140 015-21680-01 CAP CER 0805 CHIP 6P8 +/-0.25P NPO 50V
C141 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V
C142 015-22120-01 CAP CER 0805 CHIP 12P 5% NPO 50V
C145 015-23100-01 CAP CER 0805 CHIP 100P 5% NPO 50V
C146 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C147 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C148 015-22100-01 CAP CER 0805 CHIP 10P +/-0.5P NPO 50V
C149 015-23150-01 CAP CER 0805 CHIP 150P 5% NPO 50V
C150 015-23100-01 CAP CER 0805 CHIP 100P 5% NPO 50V
C151 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C152 015-23100-01 CAP CER 0805 CHIP 100P 5% NPO 50V
C152A 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C153 020-57470-10 CAP ELECT AI RDL 4U7 50V LO ESR
C153A 015-23100-01 CAP CER 0805 CHIP 100P 5% NPO 50V
C154 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C155 015-23100-01 CAP CER 0805 CHIP 100P 5% NPO 50V
C156 015-22220-01 CAP CER 0805 CHIP 22P 5% NPO 50V
C157 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C158 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C174 020-58470-05 CAP ELECT AI RDL 47M 16V 6.3X7MM
C175 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C176 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C179 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C180 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C181 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C182 015-23150-01 CAP CER 0805 CHIP 150P 5% NPO 50V
C184 015-23150-01 CAP CER 0805 CHIP 150P 5% NPO 50V
C185 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C186 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C187 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C188 015-23100-01 CAP CER 0805 CHIP 100P 5% NPO 50V
C189 015-23470-08 CAP CER 0805 CHIP 470P 10% X7R 50V
C190 015-23470-08 CAP CER 0805 CHIP 470P 10% X7R 50V
C191 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C192 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C193 020-57470-10 CAP ELECT AI RDL 4U7 50V LO ESR
C194 015-23150-01 CAP CER 0805 CHIP 150P 5% NPO 50V
C195 015-23150-01 CAP CER 0805 CHIP 150P 5% NPO 50V
C197 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C198 015-23220-01 CAP CER 0805 CHIP 220P 5% NPO 50V
C199 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C200 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C201 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C202 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C203 015-22560-01 CAP CER 0805 CHIP 56P 5% NPO 50V
C204 015-23150-01 CAP CER 0805 CHIP 150P 5% NPO 50V
C205 015-25220-08 CAP CER 0805 CHIP 22N 10% X7R 50V
C206 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C207 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C208 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C209 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C210 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C211 015-23180-01 CAP CER 0805 CHIP 180P 5% NPO 50V
C212 015-21560-01 CAP CER 0805 CHIP 5P6 +/-0.25P NPO 50V
C213 020-58470-05 CAP ELECT AI RDL 47M 16V 6.3X7MM
C214 015-23150-01 CAP CER 0805 CHIP 150P 5% NPO 50V
C215 020-57470-10 CAP ELECT AI RDL 4U7 50V LO ESR
C216 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C217 020-58470-05 CAP ELECT AI RDL 47M 16V 6.3X7MM
C218 020-57470-10 CAP ELECT AI RDL 4U7 50V LO ESR
C219 020-57470-10 CAP ELECT AI RDL 4U7 50V LO ESR
C220 022-55100-10 CAP MYLAR AI 10N 5% 63V POTTED
C221 022-57100-02 CAP MYLAR AI 1M 20% 50V POTTED
C222 022-06100-15 CAP MET POLYSTR 100N 5% 50V 5.6MM HI
C223 015-23150-01 CAP CER 0805 CHIP 150P 5% NPO 50V
C224 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C225 015-23270-01 CAP CER 0805 CHIP 270P 5% NPO 50V
C227 015-22270-01 CAP CER 0805 CHIP 27P 5% NPO 50V
C228 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C229 020-58470-05 CAP ELECT AI RDL 47M 16V 6.3X7MM
C230 015-24470-08 CAP CER 0805 CHIP 4N7 10% X7R 50V
C231 015-23270-01 CAP CER 0805 CHIP 270P 5% NPO 50V
C232 015-21470-01 CAP CER 0805 CHIP 4P7 +/-0.25P NPO 50V
C233 020-57470-10 CAP ELECT AI RDL 4U7 50V LO ESR
C234 020-57470-10 CAP ELECT AI RDL 4U7 50V LO ESR
C235 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C236 015-23150-01 CAP CER 0805 CHIP 150P 5% NPO 50V
C237 015-22270-01 CAP CER 0805 CHIP 27P 5% NPO 50V
C238 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V
C239 015-21100-01 CAP CER 0805 CHIP 1PO +/-0.25P NPO 50V
C240 015-23270-01 CAP CER 0805 CHIP 270P 5% NPO 50V
C241 015-23270-01 CAP CER 0805 CHIP 270P 5% NPO 50V
C242 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C243 015-23150-01 CAP CER 0805 CHIP 150P 5% NPO 50V
C244 015-21560-01 CAP CER 0805 CHIP 5P6 +/-0.25P NPO 50V
C245 015-21270-01 CAP CER 0805 CHIP 2P7 +/-0.25P NPO 50V
C246 015-23150-01 CAP CER 0805 CHIP 150P 5% NPO 50V
C247 015-21820-01 CAP CER 0805 CHIP 8P2 +/-0.25P NPO 50V
C249 015-23270-01 CAP CER 0805 CHIP 270P 5% NPO 50V
C250 015-22820-01 CAP CER 0805 CHIP 82P 5% NPO 50V
C251 015-23100-01 CAP CER 0805 CHIP 100P 5% NPO 50V
C252 015-23180-01 CAP CER 0805 CHIP 180P 5% NPO 50V
C253 015-22820-01 CAP CER 0805 CHIP 82P 5% NPO 50V
C300 015-03150-06 CAP CER 1210 CHIP 150P NPO 500V GRM42-2
#C301 7XX 015-23270-01 CAP CER 0805 CHIP 270P 5% NPO 50V
#C301 9XX 015-23220-01 CAP CER 0805 CHIP 220P 5% NPO 50V
#C302 7XX 015-21820-01 CAP CER 0805 CHIP 8P2 +/-0.25P NPO
#C302 9XX 015-21680-01 CAP CER 0805 CHIP 6P8 +/-0.25P NPO
#C303 7XX 015-02150-06 CAP CER 1210 CHIP 15P NPO 500V GRM4
#C303 9XX 015-02180-06 CAP CER 1210 CHIP 18P NPO 500V GRM4
C304 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
#C305 7XX 015-22150-01 CAP CER 0805 CHIP 15P 5% NPO 50V
#C305 9XX 015-22120-01 CAP CER 0805 CHIP 12P 5% NPO 50V
#C306 7XX 015-22270-01 CAP CER 0805 CHIP 27P 5% NPO 50V
#C306 9XX 015-22220-01 CAP CER 0805 CHIP 22P 5% NPO 50V
C307 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
#C308 7XX 015-22470-01 CAP CER 0805 CHIP 47P 5% NPO 50V
#C308 9XX 015-22120-01 CAP CER 0805 CHIP 12P 5% NPO 50V
#C309 7XX 015-22560-01 CAP CER 0805 CHIP 56P 5% NPO 50V
#C309 9XX 015-22220-01 CAP CER 0805 CHIP 22P 5% NPO 50V
C310 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
7.6 T2000-700/-900 RF PCB
T2000-700/-900 Parts List (IPN 220-01289-03)
Parts List Amendments
