T855 PCB Information

B6.3.5

Ref Var IPN Description Ref Var IPN Description

C640 015-24100-08 CAP CER 0805 1N 10% X7R 50V

C651 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C658 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C660 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C665 020-58100-03 CAP ELE AI RDL 10M 50V 5X11MM

C670 025-07330-01 CAP TANT BEAD 3M3 35V

C673 015-24470-08 CAP CER 0805 4N7 10% X7R 50V

C677 020-07100-02 CAP ELE RA 1M 50V 5X11MM

C681 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C684 025-08100-02 CAP TANT BEAD 10M 10% 16V

C687 015-24100-08 CAP CER 0805 1N 10% X7R 50V

C690 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C693 025-08100-02 CAP TANT BEAD 10M 10% 16V

C700 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C702 015-24100-08 CAP CER 0805 1N 10% X7R 50V

C703 015-24100-08 CAP CER 0805 1N 10% X7R 50V

C705 015-21820-01 CAP CER 0805 8P2+-1/4P NPO 50V

C707 015-22470-01 CAP CER 0805 47P 5% NPO 50V

C708 015-22470-01 CAP CER 0805 47P 5% NPO 50V

C709 015-22100-01 CAP CER 0805 10P+-1/2P NPO 50V

C710A 014-07470-00 CAP TANT CHIP 4U7 3.5 X 2.8MM

C710B 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C710C 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C711 015-22220-01 CAP CER 0805 22P 5% NPO 50V

C712 015-22220-01 CAP CER 0805 22P 5% NPO 50V

C713 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C735 015-22470-01 CAP CER 0805 47P 5% NPO 50V

C736 015-22470-01 CAP CER 0805 47P 5% NPO 50V

C740A 015-24100-08 CAP CER 0805 1N 10% X7R 50V

C740B 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C741A 014-07470-00 CAP TANT CHIP 4U7 3.5 X 2.8MM

C741B 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C742A 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C742B 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C743 015-22470-01 CAP CER 0805 47P 5% NPO 50V

C745 015-23120-01 CAP CER 0805 120P 5% NPO 50V

C750 025-08100-03 CAP 10M 35V 20% TANT 5MM L/S

C757 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C759 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C761 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C762 014-08220-01 (L)CAP TANT 22UF10V276MSER

C764 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C765 014-07470-00 CAP TANT CHIP 4U7 3.5 X 2.8MM

C767 015-24100-08 CAP CER 0805 1N 10% X7R 50V

C769 015-24100-08 CAP CER 0805 1N 10% X7R 50V

C770 014-08220-01 (L)CAP TANT 22UF10V276MSER

C772 014-08220-01 (L)CAP TANT 22UF10V276MSER

C774 022-06100-16 CAP METAL POLY 100N +-10% 100V

C776 015-24680-08 CAP CER 0805 6N8 10% X7R 50V

C782 015-23120-01 CAP CER 0805 120P 5% NPO 50V

C784 015-23120-01 CAP CER 0805 120P 5% NPO 50V

C786 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C788 015-23120-01 CAP CER 0805 120P 5% NPO 50V

C791 015-21820-01 CAP CER 0805 8P2+-1/4P NPO 50V

C792 015-23120-01 CAP CER 0805 120P 5% NPO 50V

C810 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C812 015-23100-01 CAP CER 0805 100P 5% NPO 50V

C813 015-24100-08 CAP CER 0805 1N 10% X7R 50V

C814 015-24100-08 CAP CER 0805 1N 10% X7R 50V

C815 015-05100-07 CAP 1206 CHIP NPO 10nF 25V

C816 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C818 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C819 015-22330-01 CAP CER 0805 33P 5% NPO 50V

C820 015-23220-01 CAP CER 0805 220P 5% NPO 50V

C822 015-25220-08 CAP CER 0805 22N 10% X7R 50V

C824 015-25470-08 CAP CER 0805 47N 10% X7R 50V

C826 015-05100-07 CAP 1206 CHIP NPO 10nF 25V

C828 015-05100-07 CAP 1206 CHIP NPO 10nF 25V

C830 015-25470-08 CAP CER 0805 47N 10% X7R 50V

C832 016-07100-01 CAP EL 6X4 1M 20% 50V

C833 015-25220-08 CAP CER 0805 22N 10% X7R 50V

C834 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C836 015-05100-07 CAP 1206 CHIP NPO 10nF 25V

C837 015-05100-07 CAP 1206 CHIP NPO 10nF 25V

C838 015-05100-07 CAP 1206 CHIP NPO 10nF 25V

C840 015-25470-08 CAP CER 0805 47N 10% X7R 50V

C842 016-07100-01 CAP EL 6X4 1M 20% 50V

C844 016-07100-01 CAP EL 6X4 1M 20% 50V

C846 016-07100-01 CAP EL 6X4 1M 20% 50V

C848 016-07100-01 CAP EL 6X4 1M 20% 50V

C850 015-25470-08 CAP CER 0805 47N 10% X7R 50V

C873 015-25220-08 CAP CER 0805 22N 10% X7R 50V

C876 020-09100-04 CAP ELE RA 100M 10V 6.3X9MM

C879 020-08100-04 CAP ELE RA 10M 16V 4X7MM

C910 015-21330-01 CAP CER 0805 3P3+-1/4P NPO 50V

C920 015-21680-01 CAP CER 0805 6P8+-1/4P NPO 50V

C930 015-21820-01 CAP CER 0805 8P2+-1/4P NPO 50V

C940 015-21680-01 CAP CER 0805 6P8+-1/4P NPO 50V

C950 015-21330-01 CAP CER 0805 3P3+-1/4P NPO 50V

D111 001-00011-60 S) DIODE SR2607 -- USE MR750

D220 001-10000-56 S) DIODE SMD BAW56 D-SW SOT23

D230 001-10000-70 S) DIODE SMD BAV70 D-SW SOT23

D240 001-10000-99 S) DIODE SMD BAV99 D-SW SOT23

D260 001-10084-33 S) DIODE ZEN SMD 0.3W 3V3SOT23

D270 001-10000-70 S) DIODE SMD BAV70 D-SW SOT23

D285 001-00011-70 S) DIODE 1N4001 1A/50V

D289 001-00011-70 S) DIODE 1N4001 1A/50V

D290 001-00011-70 S) DIODE 1N4001 1A/50V

D295 001-00011-70 S) DIODE 1N4001 1A/50V

D310 001-10000-56 S) DIODE SMD BAW56 D-SW SOT23

D610 001-10000-99 S) DIODE SMD BAV99 D-SW SOT23

D640 001-10000-70 S) DIODE SMD BAV70 D-SW SOT23

D730 001-10065-00 DIODE BAT65 SCHOTTKEY SOD123

D740 001-10065-00 DIODE BAT65 SCHOTTKEY SOD123

D820 001-10065-00 DIODE BAT65 SCHOTTKEY SOD123

D860 001-10000-70 S) DIODE SMD BAV70 D-SW SOT23

D880 001-10000-70 S) DIODE SMD BAV70 D-SW SOT23

#FL410 10 051-00576-00 COIL HELIC 400-440MHz T855SII

#FL410 13 051-00576-00 COIL HELIC 400-440MHz T855SII

#FL410 15 051-00576-00 COIL HELIC 400-440MHz T855SII

#FL410 20 051-00577-00 COIL HELIC 440-480MHz T855SII

#FL410 23 051-00577-00 COIL HELIC 440-480MHz T855SII

#FL410 25 051-00577-00 COIL HELIC 440-480MHz T855SII

#FL410 30 051-00578-00 COIL HELIC 480-530MHz T855SII

#FL410 35 051-00578-00 COIL HELIC 480-530MHz T855SII

#FL420 10 051-00576-00 COIL HELIC 400-440MHz T855SII

#FL420 13 051-00576-00 COIL HELIC 400-440MHz T855SII

#FL420 15 051-00576-00 COIL HELIC 400-440MHz T855SII

#FL420 20 051-00577-00 COIL HELIC 440-480MHz T855SII

#FL420 23 051-00577-00 COIL HELIC 440-480MHz T855SII

#FL420 25 051-00577-00 COIL HELIC 440-480MHz T855SII

#FL420 30 051-00578-00 COIL HELIC 480-530MHz T855SII

#FL420 35 051-00578-00 COIL HELIC 480-530MHz T855SII

IC210 002-00012-40 S) IC 358 DUAL O-AMP

IC240 002-00014-05 S) IC TDA7231 1.6W AF PWR

IC260 002-00014-05 S) IC TDA7231 1.6W AF PWR

IC270 002-00012-40 S) IC 358 DUAL O-AMP

IC280 002-00012-40 S) IC 358 DUAL O-AMP

IC310 002-00014-73 S) IC MC3361CP IF AMP

IC320 002-00014-58 S) IC 78L05 5V 100MA REG TO92

IC410 002-00022-01 S) MIXER DOUBLE BLNCD 2-750MHZ

IC610 002-00014-58 S) IC 78L05 5V 100MA REG TO92

IC630 002-00014-62 S) IC 317L 100MA REG 3TER TO92

IC640 002-10003-58 S) IC SMD LM358 DUAL O-AMP

IC650 002-10012-32 SMD DS1232LPS-2 LP RESET&W-DOG

=IC700 539-00010-50 TCXO 12.8MHZ +-1PPM -20 +70C

IC710 002-74900-04 S) IC SMD 74HC04D 6X INV BUFFD

IC740 002-14519-10 S) IC MC145191F SMD SYNTH

IC750 002-10330-78 S) IC MC33078D 2X AMP LO NOISE

IC810 002-08951-20 S) IC AT89C51 PLCC44 MIC 12MHZ

IC820 002-12416-00 SMD AT24C16N-10SC EEPROM

IC830 002-10003-24 S) IC SMD 324 4X O-AMP SO14

IC840 002-10040-53 S)MC14053B SMD BREAK B4 MAKE

IC850 002-10003-24 S) IC SMD 324 4X O-AMP SO14

L230 056-00021-02 IND FXD 100UH AX

L310 050-00016-22 COIL TAIT NO 622 20-120M

L320 050-00016-22 COIL TAIT NO 622 20-120M

L330 050-00016-22 COIL TAIT NO 622 20-120M

L340 050-00016-22 COIL TAIT NO 622 20-120M

L350 050-00016-22 COIL TAIT NO 622 20-120M

L360 050-00016-22 COIL TAIT NO 622 20-120M

L370 050-00016-22 COIL TAIT NO 622 20-120M

L380 050-00016-22 COIL TAIT NO 622 20-120M

L385 050-00016-22 COIL TAIT NO 622 20-120M

L390 050-00016-31 COIL TAIT NO 631 455KHZ

L420 056-00021-04 IND FXD 330NH AX

L440 056-00021-04 IND FXD 330NH AX

L740 052-08125-15 COIL A/W 1.5T/2.5MM HOR 0.8MM

L910 052-08125-25 COIL A/W 2.5T/2.5MM HOR 0.8MM

L920 052-08140-15 COIL A/W 1.5T/4.0MM HOR 0.8MM

L930 052-08140-15 COIL A/W 1.5T/4.0MM HOR 0.8MM

L940 052-08125-25 COIL A/W 2.5T/2.5MM HOR 0.8MM

PL210 240-00020-59 HEADER 3 W 1 R PCB MTG

PL220 240-00020-59 HEADER 3 W 1 R PCB MTG

PL230 240-00020-63 HEADER 4 W X1R PCB MTG

PL240 240-00020-58 HEADER 5 WX1 R PCB MTG

PL250 240-00020-59 HEADER 3 W 1 R PCB MTG

PL260 240-00020-59 HEADER 3 W 1 R PCB MTG

PL270 240-00020-59 HEADER 3 W 1 R PCB MTG

Q210 000-10008-48 S) XSTR SMD BCW60 NPN SOT23 SS

Q220 000-10008-48 S) XSTR SMD BCW60 NPN SOT23 SS

Q230 000-10008-48 S) XSTR SMD BCW60 NPN SOT23 SS

Q240 000-10008-57 S) XSTR SMD BCW70 PNP SOT23 SS

Q245 000-10008-57 S) XSTR SMD BCW70 PNP SOT23 SS

Q250 000-10008-48 S) XSTR SMD BCW60 NPN SOT23 SS

Q255 000-10008-57 S) XSTR SMD BCW70 PNP SOT23 SS

Q260 000-10008-48 S) XSTR SMD BCW60 NPN SOT23 SS

Q270 000-10008-17 S) XSTR SMD BC817-25 NPN SOT23

Q280 000-10008-48 S) XSTR SMD BCW60 NPN SOT23 SS

Q290 000-10008-48 S) XSTR SMD BCW60 NPN SOT23 SS

Q310 000-50020-18 S) XSTR AI BF247A JFETTO92 VHF

Q320 000-10008-92 S) XSTR SMD BFS17 NPN SOT23

Q330 000-10009-91 S) XSTR SMD BF991 DG MFET

Q340 000-10008-48 S) XSTR SMD BCW60 NPN SOT23 SS

Q350 000-10008-48 S) XSTR SMD BCW60 NPN SOT23 SS

Q360 000-10008-48 S) XSTR SMD BCW60 NPN SOT23 SS

Q410 000-10057-10 S) XSTR SMD BR571 NPN SOT23

Q540 000-10008-48 S) XSTR SMD BCW60 NPN SOT23 SS

Q620 000-00012-15 S) XSTR BD234 PNP AF PWR TO126

Q630 000-50011-30 S) XSTR AI BC557B PNP TO92 AF
