IPN 220-01397-01

M850-00

T856 PCB Information

C6.2.5

Ref Var IPN Description Ref Var IPN Description

#C460 15 029-02220-02 CAP MICA 5 CASE 22P 5%

#C460 20 029-02270-02 CAP MICA 5 CASE 27P 5%

#C460 23 029-02270-02 CAP MICA 5 CASE 27P 5%

#C460 25 029-02270-02 CAP MICA 5 CASE 27P 5%

#C460 30 029-02220-02 CAP MICA 5 CASE 22P 5%

#C460 35 029-02220-02 CAP MICA 5 CASE 22P 5%

#C465 10 029-02220-02 CAP MICA 5 CASE 22P 5%

#C465 13 029-02220-02 CAP MICA 5 CASE 22P 5%

#C465 15 029-02220-02 CAP MICA 5 CASE 22P 5%

#C465 20 029-02270-02 CAP MICA 5 CASE 27P 5%

#C465 23 029-02270-02 CAP MICA 5 CASE 27P 5%

#C465 25 029-02270-02 CAP MICA 5 CASE 27P 5%

#C465 30 029-02220-02 CAP MICA 5 CASE 22P 5%

#C465 35 029-02220-02 CAP MICA 5 CASE 22P 5%

C470 015-03100-03 CAP CER 100P 5% NPO500V GRH111

#C480 10 NOT PLACED

#C480 13 NOT PLACED

#C480 15 NOT PLACED

#C480 20 015-01470-02 CAP CER HIQ1210 4P7 5% NPO200V

#C480 23 015-01470-02 CAP CER HIQ1210 4P7 5% NPO200V

#C480 25 015-01470-02 CAP CER HIQ1210 4P7 5% NPO200V

#C480 30 NOT PLACED

#C480 35 NOT PLACED

C481 015-23150-01 CAP CER 0805 150P 5% NPO 50V

C485 015-23150-01 CAP CER 0805 150P 5% NPO 50V

C490 015-23150-01 CAP CER 0805 150P 5% NPO 50V

C493 015-03100-03 CAP CER 100P 5% NPO500V GRH111

C496 015-23150-01 CAP CER 0805 150P 5% NPO 50V

C499 015-23150-01 CAP CER 0805 150P 5% NPO 50V

C501 015-23150-01 CAP CER 0805 150P 5% NPO 50V

C502 015-23150-01 CAP CER 0805 150P 5% NPO 50V

C503 015-24470-08 CAP CER 0805 4N7 10% X7R 50V

C504 015-23150-01 CAP CER 0805 150P 5% NPO 50V

C505 015-25470-08 CAP CER 0805 47N 10% X7R 50V

C507 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C508 015-23150-01 CAP CER 0805 150P 5% NPO 50V

C509 015-23150-01 CAP CER 0805 150P 5% NPO 50V

C510 015-25470-08 CAP CER 0805 47N 10% X7R 50V

C512 015-23150-01 CAP CER 0805 150P 5% NPO 50V

C513 015-23150-01 CAP CER 0805 150P 5% NPO 50V

C514 015-23150-01 CAP CER 0805 150P 5% NPO 50V

C516 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C517 015-23150-01 CAP CER 0805 150P 5% NPO 50V

C519 015-23150-01 CAP CER 0805 150P 5% NPO 50V

C525 015-23150-01 CAP CER 0805 150P 5% NPO 50V

C530 014-08220-01 (L)CAP TANT 22UF10V276MSER

C535 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C537 015-23150-01 CAP CER 0805 150P 5% NPO 50V

C605 015-23120-01 CAP CER 0805 120P 5% NPO 50V

C610A 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C610B 020-09100-04 CAP ELE RA 100M 10V 6.3X9MM

C611A 020-09100-04 CAP ELE RA 100M 10V 6.3X9MM

C611B 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C620 015-23150-01 CAP CER 0805 150P 5% NPO 50V

C621 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C623 015-23120-01 CAP CER 0805 120P 5% NPO 50V

C625 020-09470-07 CAPEL470M16V20%V 8*20 3.5L.ESR

C626 015-24470-08 CAP CER 0805 4N7 10% X7R 50V

C628 015-24100-08 CAP CER 0805 1N 10% X7R 50V

C630 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C631A 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C634 014-08100-00 CAP TANT CHIP 10M 16VW +-20%

C636 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C638 015-23120-01 CAP CER 0805 120P 5% NPO 50V

C640 015-24100-08 CAP CER 0805 1N 10% X7R 50V

C655 015-24100-08 CAP CER 0805 1N 10% X7R 50V

C660 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C665 020-58100-03 CAP ELE AI RDL 10M 50V 5X11MM

C670 025-07330-01 CAP TANT BEAD 3M3 35V

C673 015-24470-08 CAP CER 0805 4N7 10% X7R 50V

C677 020-07100-02 CAP ELE RA 1M 50V 5X11MM

C681 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C684 014-08100-00 CAP TANT CHIP 10M 16VW +-20%

C687 015-23120-01 CAP CER 0805 120P 5% NPO 50V

C690 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C693 014-08100-00 CAP TANT CHIP 10M 16VW +-20%

C700 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C701 015-23150-01 CAP CER 0805 150P 5% NPO 50V

C703 015-24100-08 CAP CER 0805 1N 10% X7R 50V

C705 015-21820-01 CAP CER 0805 8P2+-1/4P NPO 50V

C706 015-22470-01 CAP CER 0805 47P 5% NPO 50V

C708 014-07470-00 CAP TANT CHIP 4U7 3.5 X 2.8MM

C709 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C710 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C712 015-22470-01 CAP CER 0805 47P 5% NPO 50V

C720 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C722 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C724 014-08220-01 (L)CAP TANT 22UF10V276MSER

C725 014-08220-01 (L)CAP TANT 22UF10V276MSER

C726 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C727 015-23220-01 CAP CER 0805 220P 5% NPO 50V

C729 015-23220-01 CAP CER 0805 220P 5% NPO 50V

%C733 015-23470-08 CAP CER 0805 470P 10% X7R 50V

C735 015-22470-01 CAP CER 0805 47P 5% NPO 50V

C736 015-22470-01 CAP CER 0805 47P 5% NPO 50V

C740A 015-24100-08 CAP CER 0805 1N 10% X7R 50V

C740B 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C741A 014-07470-00 CAP TANT CHIP 4U7 3.5 X 2.8MM

C741B 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C742A 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C742B 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C743 015-22470-01 CAP CER 0805 47P 5% NPO 50V

C745 015-23120-01 CAP CER 0805 120P 5% NPO 50V

C750A 025-08100-03 CAP 10M 35V 20% TANT 5MM L/S

C750B 015-24100-08 CAP CER 0805 1N 10% X7R 50V

C757 015-25220-08 CAP CER 0805 22N 10% X7R 50V

C759 015-25470-08 CAP CER 0805 47N 10% X7R 50V

C761 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C762 014-08220-01 (L)CAP TANT 22UF10V276MSER

C763 015-23150-01 CAP CER 0805 150P 5% NPO 50V

C764 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C765 015-23150-01 CAP CER 0805 150P 5% NPO 50V

C766 014-07470-00 CAP TANT CHIP 4U7 3.5 X 2.8MM

C767 015-24100-08 CAP CER 0805 1N 10% X7R 50V

C768 015-23150-01 CAP CER 0805 150P 5% NPO 50V

C769 015-24100-08 CAP CER 0805 1N 10% X7R 50V

C770 014-08220-01 (L)CAP TANT 22UF10V276MSER

C772 014-08220-01 (L)CAP TANT 22UF10V276MSER

C774 022-06100-16 CAP METAL POLY 100N +-10% 100V

C776 015-24470-08 CAP CER 0805 4N7 10% X7R 50V

C782 015-23120-01 CAP CER 0805 120P 5% NPO 50V

C784 015-23120-01 CAP CER 0805 120P 5% NPO 50V

C786 015-06100-08 CAP CER 1206 100N 10% X7R 50V

C788 015-23120-01 CAP CER 0805 120P 5% NPO 50V

C790 015-21820-01 CAP CER 0805 8P2+-1/4P NPO 50V

C792 015-23120-01 CAP CER 0805 120P 5% NPO 50V

C810 015-25470-08 CAP CER 0805 47N 10% X7R 50V

C812 015-23100-01 CAP CER 0805 100P 5% NPO 50V

C813 015-24100-08 CAP CER 0805 1N 10% X7R 50V

C822 014-07470-00 CAP TANT CHIP 4U7 3.5 X 2.8MM

C823 015-25220-08 CAP CER 0805 22N 10% X7R 50V

C824 015-25470-08 CAP CER 0805 47N 10% X7R 50V

C826 015-23220-01 CAP CER 0805 220P 5% NPO 50V

C827 015-22330-01 CAP CER 0805 33P 5% NPO 50V

C828 015-25100-08 CAP CER 0805 10N 10% X7R 50V

C830 015-25470-08 CAP CER 0805 47N 10% X7R 50V

C838 020-09100-04 CAP ELE RA 100M 10V 6.3X9MM

C841 020-09100-04 CAP ELE RA 100M 10V 6.3X9MM

C844 015-25100-08 CAP CER 0805 10N 10% X7R 50V

#C900 10 015-01560-06 CAP CER 1210 5P6 NPO500VGRM42

#C900 13 015-01560-06 CAP CER 1210 5P6 NPO500VGRM42

#C900 15 015-01560-06 CAP CER 1210 5P6 NPO500VGRM42

#C900 20 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42

#C900 23 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42

#C900 25 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42

#C900 30 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42

#C900 35 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42

C910 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42

#C920 10 015-01470-06 CAP CER 1210 4P7 NPO500VGRM42

#C920 13 015-01470-06 CAP CER 1210 4P7 NPO500VGRM42

#C920 15 015-01470-06 CAP CER 1210 4P7 NPO500VGRM42

#C920 20 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42

#C920 23 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42

#C920 25 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42

#C920 30 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42

#C920 35 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42

#C930 10 015-21100-01 CAP CER 0805 1PO+-1/4P NPO 50V

#C930 13 015-21100-01 CAP CER 0805 1PO+-1/4P NPO 50V

#C930 15 015-21100-01 CAP CER 0805 1PO+-1/4P NPO 50V

#C930 20 NOT PLACED

#C930 23 NOT PLACED

#C930 25 NOT PLACED

#C930 30 NOT PLACED

#C930 35 NOT PLACED

C940 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42

#C950 10 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42

#C950 13 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42

#C950 15 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42

#C950 20 015-01470-06 CAP CER 1210 4P7 NPO500VGRM42

#C950 23 015-01470-06 CAP CER 1210 4P7 NPO500VGRM42

#C950 25 015-01470-06 CAP CER 1210 4P7 NPO500VGRM42

#C950 30 015-01470-06 CAP CER 1210 4P7 NPO500VGRM42

#C950 35 015-01470-06 CAP CER 1210 4P7 NPO500VGRM42

#C960 10 015-21100-01 CAP CER 0805 1PO+-1/4P NPO 50V

#C960 13 015-21100-01 CAP CER 0805 1PO+-1/4P NPO 50V

#C960 15 015-21100-01 CAP CER 0805 1PO+-1/4P NPO 50V

#C960 20 NOT PLACED

#C960 23 NOT PLACED

#C960 25 NOT PLACED

#C960 30 NOT PLACED

#C960 35 NOT PLACED

C970 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42

#C980 10 015-01470-06 CAP CER 1210 4P7 NPO500VGRM42

#C980 13 015-01470-06 CAP CER 1210 4P7 NPO500VGRM42

#C980 15 015-01470-06 CAP CER 1210 4P7 NPO500VGRM42

#C980 20 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42

#C980 23 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42

#C980 25 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42

#C980 30 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42

#C980 35 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42

#C990 10 015-01560-06 CAP CER 1210 5P6 NPO500VGRM42

#C990 13 015-01560-06 CAP CER 1210 5P6 NPO500VGRM42

#C990 15 015-01560-06 CAP CER 1210 5P6 NPO500VGRM42

#C990 20 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42

#C990 23 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42

#C990 25 015-01390-06 CAP CER 1210 3P9 NPO500VGRM42
