IPN 220-01397-01
M850-00
T856 PCB Information
C6.2.13
Copyright TEL 31/09/98
Device PCB Circuit Device PCB CircuitDevice PCB Circuit Device PCB Circuit
T856 Grid Reference Index (IPN 220-01397-01)
How To Use This Grid Reference Index
The first digit in the PCB layout reference is a "1" or "2", indicating the top or bottom side layout respectively, and the last two charac-
ters give the location of the component on that diagram.
The first digit in the circuit diagram reference is the sheet number, and the last two characters give the location of the component on
that sheet.
C201 1:C1 2-B8
C202 1:C1 2-C8
C204 1:A2 2-E8
C205 1:A2 2-E8
C207 1:C7 2-B6
C209 1:C6 2-D6
C210 1:C7 2-K0
C211 1:B7 2-F8
C213 1:B6 2-G8
C215 1:B6 2-G8
C217 1:C6 2-H8
C219 1:C6 2-H7
C221 1:D5 2-G6
C223 1:C5 2-J6
C225 1:C3 2-K7
C227 1:B4 2-K7
C229 1:B3 2-L7
C230 1:B4 2-J0
C232 1:A4 2-M7
C233 1:A5 2-N7
C235 1:B5 2-K5
C237 1:C4 2-K5
C239 1:C4 2-L4
C241 1:B4 2-M6
C242 1:B4 2-L6
C243 1:B4 2-P6
C245 1:C5 2-A4
C247 1:D4 2-B4
C249 1:D4 2-C4
C251 1:C3 2-E4
C253 1:D3 2-E3
C255 1:D3 2-D2
C257 1:D3 2-F2
C259 1:C6 2-J2
C260 1:D8 2-H0
C261 1:C6 2-K2
C263 1:D6 2-L3
C265 1:D6 2-N4
C267 1:C8 2-P3
&C269 1:C8 2-P3
C271 1:C8 2-Q3
C273 1:C8 2-Q4
C275 1:D3 2-E1
C277 1:C4 2-G1
C279 1:B4 2-G1
C281 1:B5 2-J1
C283 1:B5 2-K0
C285 1:D7 2-L0
C287 1:C6 2-M1
C289 1:C8 2-N1
C291 1:D7 2-P1
C293 1:D7 2-Q1
%C294 1:D7 2-Q0
%C295 1:D6 2-Q0
C300 1:F8 3-B8
C301 1:F9 3-B7
C302 1:E8 3-A6
C303 1:E8 3-A6
C304 1:E8 3-C6
C305 1:F7 3-E5
C306 1:F7 3-F7
C307 1:F7 3-F7
C308 1:F8 3-G7
C309 1:F8 3-J7
C310 1:F8 3-K7
C311 1:F8 3-G6
C312 1:F8 3-G5
C313 1:E9 3-C8
C314 1:F8 3-G5
C315 1:E8 3-C7
C316 1:F8 3-H6
C317 1:F8 3-H5
C318 1:F8 3-J5
C320 1:F5 3-P5
C324 1:F6 3-Q5
C326 1:F6 3-Q4
C327 1:F7 3-C3
C328 1:F6 3-R4
C329 1:F6 3-R4
C330A 1:E8 3-G8
C330B 1:E8 3-G8
C331 1:F3 3-B2
C332 1:F8 3-B3
C333 1:F3 3-B0
C334 1:F7 3-C3
C335 1:F7 3-F5
C336 1:F7 3-F5
C337 1:E7 3-F3
C338 1:E7 3-F2
C339 1:E7 3-F3
C340 1:E7 3-H4
C341 1:F3 3-G3
C342 1:F3 3-H3
C343 1:F3 3-J3
C344 1:F3 3-J4
C345 1:F3 3-K4
C346 1:F3 3-K4
C347 1:F3 3-L4
C348 1:F3 3-M4
C349 1:F3 3-M4
C350A 1:F7 3-J8
C350B 1:F7 3-J8
C351 1:F4 3-H1
C352 1:F4 3-J0
C353 1:F4 3-J0
C354 1:F4 3-K0
C355 1:F4 3-K1
C356 1:F3 3-K2
C358 1:E4 3-K1
C360 1:E4 3-L1
C362 1:E5 3-N2
C364 1:E4 3-M2
C366 1:F4 3-N2
C368 1:E5 3-N1
C370A 1:F8 3-K7
C370B 1:F8 3-L7
C370C 1:F8 3-L7
C371 1:F8 3-N7
C372 1:F9 3-P7
C373 1:F9 3-P7
C380 1:E6 3-P1
#C382 1:E6 3-Q1
C383 1:F3 3-B2
#C384 1:E6 3-R2
C385 1:F3 3-D0
C405 2:H8 4-D4
#C410 2:J8 4-E3
C415 2:J7 4-F3
C419 1:G8 4-C6
C420 1:G8 4-D6
C421 1:G8 4-D6
C430 1:J7 4-H6
C435 1:M7 4-J6
C438 2:K8 4-G4
#C440 2:K8 4-H4
#C445 2:K7 4-J4
C450 1:L7 4-K5
C455 1:M7 4-L5
#C460 2:L7 4-K4
#C465 2:L8 4-L4
C470 2:L8 4-M4
#C480 2:M8 4-N4
C481 1:J8 4-P7
C485 1:M9 4-M5
C490 1:M9 4-N5
C493 2:M8 4-N4
C496 1:N7 4-P3
C499 1:N7 4-Q3
C501 1:K4 5-B6
C502 1:K4 5-C6
C503 1:K6 5-L9
C504 1:K6 5-M6
C505 1:K6 5-N6
C507 1:K6 5-B5
C508 1:K6 5-C0
C509 1:K6 5-D0
C510 1:J5 5-D1
C512 1:J5 5-E1
C513 1:J5 5-H1
C514 1:J5 5-J1
C516 1:H5 5-H4
C517 1:H5 5-H4
C519 1:H5 5-J5
C525 1:K4 5-K5
C530 1:K5 5-L4
C535 1:K5 5-L2
C537 1:K5 5-N2
C605 1:L6 6-D8
C610A 1:M5 6-F8
C610B 1:M5 6-G8
C611A 1:L5 6-H8
C611B 1:M5 6-J8
C620 1:N5 6-K9
C621 1:N5 6-L9
C623 1:N6 6-N7
C625 1:M6 6-Q8
C626 1:M6 6-R8
C628 1:M6 6-R8
C630 1:M5 6-K4
C631A 1:M5 6-M5
C634 1:N5 6-M4
C636 1:M5 6-M4
C638 1:M6 6-P5
C640 1:M5 6-R5
C655 1:M4 6-C1
C660 1:L5 6-K1
C665 1:L5 6-K1
C670 1:L6 6-L1
C673 1:L5 6-P2
C677 1:L6 6-P1
C681 1:M5 6-R3
C684 1:M6 6-R3
C687 1:L6 6-Q1
C690 1:L6 6-R1
C693 1:L6 6-R1
C700 1:K4 7-A8
C701 1:J3 7-B8
C703 1:J3 7-B7
C705 1:J3 7-B7
C706 1:J2 7-B5
%C707 1:K4 7-C8
C708 1:J2 7-C9
C709 1:K4 7-D9
C710 1:J3 7-E8
C712 1:H2 7-E7
%C713 1:H2 7-E6
C720 1:J3 7-F8
C722 1:J4 7-G8
C724 1:J4 7-H6
C725 1:J4 7-J6
C726 1:K4 7-J6
C727 1:J3 7-J8
C729 1:J3 7-M8
%C733 1:J3 7-M5
C735 1:J2 7-A1
C736 1:J2 7-B1
C740A 1:H2 7-B4
C740B 1:H2 7-B3
C741A 1:H2 7-C4
C741B 1:G2 7-C3
C742A 1:H2 7-D4
C742B 1:H3 7-D3
C743 1:H2 7-B1
C745 1:G3 7-D1
C750A 1:H4 7-Q7
C750B 1:H4 7-R7
C757 1:G4 7-F5
C759 1:G4 7-G4
C761 1:G3 7-J4
C762 1:G3 7-J4
C763 1:H3 7-K4
C764 1:H3 7-H2
C765 1:G3 7-J2
C766 1:G3 7-J2
C767 1:H3 7-K3
C768 1:H4 7-L4
