Tait T850 II Series - Page 217

IPN 220-01397-01
M850-00 T856 PCB Information
C6.2.15
Copyright TEL 31/09/98
Device PCB Circuit Device PCB Circuit Device PCB CircuitDevice PCB Circuit
R232 1:B4 2-M5
R233 1:B4 2-M6
R235 1:B4 2-P6
R237 1:B7 2-Q7
R238 1:B7 2-R7
R239 1:B8 2-R6
R241 1:B8 2-Q6
R242 1:B7 2-Q5
R244 1:C6 2-A5
R245 1:D4 2-D4
R247 1:D3 2-E4
R248 1:C3 2-E3
R249 1:D4 2-F3
R251 1:C4 2-G4
R253 1:C6 2-J2
R254 1:C6 2-K3
R255 1:C7 2-K2
R256 1:D8 2-M3
R257 1:D8 2-N5
R258 1:D8 2-N4
R259 1:D5 2-P4
R260 1:D8 2-N4
R262 1:D8 2-N3
R263 1:C8 2-P3
&R264 1:C8 2-P3
&R265 1:C8 2-P3
&R266 1:C8 2-P3
R267 1:C8 2-R2
R268 1:D2 2-C0
R269 1:C2 2-C1
R270 1:C2 2-D1
R271 1:C3 2-E1
R272 1:C4 2-F2
R273 1:B5 2-G2
R274 1:C4 2-G1
R275 1:C4 2-H0
R277 1:B5 2-J1
R278 1:B5 2-J0
R279 1:B5 2-K0
R280 1:B5 2-K0
R282 1:D7 2-K1
R283 1:D7 2-L1
R284 1:D7 2-L0
R285 1:C8 2-M0
R286 1:C7 2-M0
R287 1:D9 2-M0
R288 1:C6 2-M2
R289 1:D9 2-M0
R290 1:C8 2-N2
R291 1:C8 2-N1
R292 1:D8 2-Q2
R293 1:D9 2-Q2
R294 1:D9 2-Q1
R295 1:D8 2-R1
R296 1:D6 2-P0
R297 1:D7 2-P1
%R298 1:D7 2-Q0
R299 1:C7 2-R0
R300 1:F8 3-B9
R301 1:E9 3-C8
R302 1:F9 3-B7
R303 1:E8 3-C7
R304 1:E8 3-E9
R305 1:E8 3-E7
R306 1:E8 3-B6
R307 1:E8 3-B6
R309 1:E8 3-C6
R311 1:E7 3-D6
R315 1:E7 3-D6
%R317 1:F7 3-D5
R319 1:F7 3-E5
R321 1:F7 3-G5
R323 1:F8 3-G7
R324 1:F7 3-F5
R325 1:F8 3-G5
R327 1:F8 3-H7
R329 1:F5 3-P5
R330 1:E8 3-H9
R333 1:F6 3-P4
R334 1:F3 3-C1
R335 1:F6 3-R4
R337 1:F5 3-R5
R338 1:F9 3-B4
R339 1:E7 3-B4
R341 1:F7 3-C4
R343 1:F7 3-D4
R345 1:E7 3-D4
R347 1:F7 3-E3
R349 1:E7 3-F3
R350 1:F8 3-K9
R351 1:E7 3-F2
R352 1:F3 3-B2
R353 1:E7 3-G2
R354 1:F3 3-C2
R355 1:E7 3-G3
R357 1:E7 3-G4
R359 1:E7 3-H3
R360 1:F3 3-H3
R361 1:F3 3-H3
R362 1:F3 3-J4
R363 1:F3 3-J4
R365 1:F3 3-J3
R367 1:F3 3-K4
R368 1:F4 3-L3
R369 1:F3 3-L4
R370 1:F8 3-K8
R371 1:E8 3-N7
R372 1:E8 3-N7
R373 1:E8 3-N7
R374 1:E9 3-N6
R376 1:F3 3-L2
R381 1:F4 3-H1
R382 1:F4 3-J1
R383 1:F4 3-J0
R384 1:F4 3-J1
R385 1:E4 3-L1
R386 1:F4 3-L2
R387 1:E4 3-M2
R389 1:E4 3-M2
R390 1:E4 3-M2
R391 1:E4 3-M2
R392 1:E4 3-M2
R393 1:F4 3-N2
R394 1:F4 3-P2
#R395 1:E5 3-N1
#R396 1:E5 3-N2
#R397 1:E5 3-N1
R399 1:E6 3-P1
#R410 1:H8 4-B4
#R420 1:H8 4-B3
#R430 1:H8 4-B3
#R440 1:H8 4-C3
R450 1:G7 4-D3
R460 1:M8 4-P5
R470 2:N8 4-P5
R480 2:M8 4-N4
R481 1:J9 4-P7
R490 1:N7 4-P3
R500 1:J4 5-C6
R501 1:J6 5-J8
R502 1:J6 5-J8
R503 1:J6 5-K8
R504 1:K6 5-K9
R505 1:K6 5-L8
R510 1:K6 5-L8
R514 1:K6 5-N6
R515 1:H6 5-H5
#R517 1:G5 5-F2
#R518 1:G5 5-F3
#R519 1:G5 5-G2
R520 1:K6 5-C1
R523 1:J5 5-D1
R525 1:J5 5-D1
R530 1:J5 5-E1
R535 1:J5 5-F1
R540 1:H5 5-K4
R545 1:K5 5-H0
%R550 1:K5 5-K2
%R551 1:K5 5-L2
R555 1:K5 5-L3
R560 1:K4 5-L5
R609 1:L6 6-B8
R613 1:L6 6-C8
R615 1:M5 6-F9
R617 1:M5 6-J8
R619 1:M6 6-L8
R621 1:M6 6-L7
R625 1:N6 6-L7
R629 1:M6 6-P6
R633 1:M5 6-Q8
R637 1:N5 6-K5
R641 1:N5 6-L4
R645 1:N5 6-L5
R649 1:M5 6-M5
R653 1:M5 6-Q4
R657 1:M5 6-D1
R661 1:M5 6-E3
R665 1:M5 6-E2
R669 1:M5 6-E2
R673 1:M5 6-E0
R677 1:M4 6-F4
R681 1:L5 6-L2
R685 1:L5 6-N2
R689 1:L6 6-Q3
R693 1:L6 6-Q1
R696 1:M6 6-Q1
R701 1:K4 7-A9
R702 1:K4 7-C9
R703 1:J3 7-C8
=R705 1:K3 7-A7
R706 1:J3 7-B6
R708 1:H3 7-C7
R710 1:H2 7-E7
R711 1:J2 7-B6
R712 1:J3 7-D9
R713 1:J4 7-F8
%R715 1:K4 7-H6
R717 1:J4 7-H7
R718 1:J4 7-H7
R719 1:J4 7-J6
R720 1:J3 7-K7
R721 1:J3 7-K9
R722 1:J3 7-K8
R723 1:J3 7-M7
R725 1:J4 7-N7
%R726 1:J3 7-N6
R727 1:H3 7-N9
R728 1:H3 7-N8
R742 1:H2 7-B4
R743 1:H2 7-C5
R744 1:G2 7-D4
R746 1:H3 7-E4
R747 1:H3 7-E5
R748 1:J2 7-A1
R749 1:J2 7-B1
R750 1:H4 7-Q7
R752 1:G4 7-F5
R753 1:G4 7-F3
R754 1:G3 7-F3
R756 1:G3 7-G5
R757 1:G4 7-G4
R758 1:H3 7-H4
R759 1:H3 7-H4
R760 1:H3 7-K4
R762 1:H3 7-K4
R763 1:H4 7-L4
R765 1:H3 7-H2
R766 1:G3 7-J3
R767 1:H3 7-K2
R769 1:H3 7-K3
R771 1:H4 7-L3
R772 1:G4 7-M2
R774 1:H4 7-M3
R775 1:H4 7-N2
R777 1:H4 7-R2
R780 1:G2 7-P1
R782 1:G3 7-P1
R784 1:G3 7-P1
R785 1:G3 7-Q1
R786 1:G2 7-R1
R787 1:G2 7-R2
R790 1:G3 7-P0
R791 1:G3 7-Q0
R801 1:M2 8-D7
R802 1:M2 8-D7
R808 1:L2 8-B4
R809 1:L2 8-D5
R810 1:L2 8-D6
R811 1:L2 8-E6
R812 1:L2 8-D5
R813 1:L2 8-D4
R815 1:L2 8-F4
R816 1:L2 8-F4
R818 1:M2 8-F5
R819 1:M2 8-F5
R821 1:M4 8-B3
R822 1:M4 8-E3
R824 1:L4 8-L8
R825 1:L4 8-L8
R826 1:L4 8-L8
R827 1:L4 8-L7
R828 1:L4 8-L7
R829 1:L4 8-P9
R830 1:L3 8-P9
R831 1:L3 8-P9
R832 1:L3 8-P8
R833 1:L3 8-P8
R835 1:L3 8-P8
R836 1:L3 8-P8
R837 1:L3 8-P7
R840 1:L3 8-P7
R841 1:L3 8-P7
R842 1:L3 8-P6
R843 1:L3 8-P6
R845 1:M4 8-P5
R846 1:K2 8-P4
R847 1:K2 8-P4
R848 1:L2 8-J4
R849 1:M4 8-P3
R850 1:K2 8-P4
R853 1:M4 8-N3
R854 1:M4 8-N3
R855 1:M2 8-B0
R859 1:N2 8-C1
R861 1:N2 8-D1
R863 1:N3 8-E1
R865 1:N4 8-E0
R867 1:N3 8-E1
R871 1:N3 8-G2
R872 1:M4 8-H1
R873 1:N3 8-G1
R874 1:N3 8-H0
R875 1:N3 8-G0
R876 1:N3 8-H0
R877 1:M2 8-K2
R879 1:N2 8-L3
RV210 1:B7 2-F9
RV220 1:A4 2-M6
RV310 1:E7 3-D6
RV320 1:E8 3-B4
RV330 1:F7 3-E5
RV805 1:N4 8-F1
