Tait T850 II Series User Manual

IPN 220-01159-01
D5.3.6
T859 PCB Information M850-00
31/09/98 Copyright TEL
Ref Var IPN Description Ref Var IPN Description
L35 051-00005-60 IND HAIRPIN 10MM TALL T859
L36 065-00010-04 BEAD FERRITE F8 4X2X5MM
L37 065-00010-04 BEAD FERRITE F8 4X2X5MM
L38 051-00005-60 IND HAIRPIN 10MM TALL T859
L39 051-00005-54 COUPLER WIRELINE TAIT COIL DWG NO 554
L41 056-00021-04 IND FXD 330NH AXIAL
*L42 LOW 052-08340-10 COIL A/W 1T/4.0MM SMD 0.8MM WIRE
*L42 MID 052-08330-10 COIL A/W 1T/3.0MM SMD 0.8MM WIRE
*L42 HI 052-08330-10 COIL A/W 1T/3.0MM SMD 0.8MM WIRE
L43 052-08335-10 COIL A/W 1T/3.5MM SMD 0.8MM WIRE
*L45 LOW 052-08345-20 COIL A/W 2T/4.5MM SMD 0.8MM WIRE
*L45 MID 052-08335-20 COIL A/W 2T/3.5MM SMD 0.8MM WIRE
*L45 HI 052-08335-20 COIL A/W 2T/3.5MM SMD 0.8MM WIRE
*L46 LOW 052-08345-20 COIL A/W 2T/4.5MM SMD 0.8MM WIRE
*L46 MID 052-08340-20 COIL A/W 2T/4.0MM SMD 0.8MM WIRE
*L46 HI 052-08340-20 COIL A/W 2T/4.0MM SMD 0.8MM WIRE
*L47 LOW 052-08340-20 COIL A/W 2T/4.0MM SMD 0.8MM WIRE
*L47 MID 052-08335-20 COIL A/W 2T/3.5MM SMD 0.8MM WIRE
*L47 HI 052-08335-20 COIL A/W 2T/3.5MM SMD 0.8MM WIRE
L49 056-00021-04 IND FXD 330NH AXIAL
L51 056-00021-04 IND FXD 330NH AXIAL
L52 051-00005-53 COIL TAIT NO 553 A/W 10MM LINK T858/9
Q1 000-00022-71 (S) XSTR SD1135 NPN STUD MTG UHF PWR 5W
Q3 000-00032-79 (S) XSTR MRF654 UHF PWR 15W STUD
Q4 000-00032-67 (S) XSTR MRF648 UHF PWR 60W 6LFL
Q6 000-00032-67 (S) XSTR MRF648 UHF PWR 60W 6LFL
Q7 000-00032-67 (S) XSTR MRF648 UHF PWR 60W 6LFL
Q10 000-00020-70 (S) XSTR BS170 JFET TO-92 SMALL SIG
Q11 000-10008-17 (S) XSTR SMD BC817-25 NPN SOT-23 AF LO PWR
Q12 000-00020-70 (S) XSTR BS170 JFET TO-92 SMALL SIG
Q13 000-10008-17 (S) XSTR SMD BC817-25 NPN SOT-23 AF LO PWR
Q15 000-10008-17 (S) XSTR SMD BC817-25 NPN SOT-23 AF LO PWR
Q16 000-00030-95 (S) XSTR 2N6107 PNP TO-220 AF PWR
Q17 000-10008-57 (S) XSTR SMD BCW70/BC857-215 PNP SOT23 AF
Q18 000-00011-70 (S) XSTR BD136 PNP AF PWR TO126
Q19 000-10008-57 (S) XSTR SMD BCW70/BC857-215 PNP SOT23 AF
Q20 000-10008-17 (S) XSTR SMD BC817-25 NPN SOT-23 AF LO PWR
Q21 000-10008-17 (S) XSTR SMD BC817-25 NPN SOT-23 AF LO PWR
R1 030-53470-20 RES FILM AI 470E 5% 0.4W 4X1.6MM
R2 030-02120-20 RES FILM 12E 5% 0.4W 4X1.6MM
R3 030-53470-20 RES FILM AI 470E 5% 0.4W 4X1.6MM
*R7 LOW 030-52330-20 RES FILM AI 33E 5% 0.4W 4X1.6MM
*R7 MID 030-52330-20 RES FILM AI 33E 5% 0.4W 4X1.6MM
*R7 HI 030-52680-20 RES FILM AI 68E 5% 0.4W 4X1.6MM
R8 032-33100-00 RES M/F PWR 100E 5% 1W 10X4MM
*R11 LOW 032-32100-00 RES M/F PWR 10E 5% 1W 10X4MM
*R11 MID 032-32100-00 RES M/F PWR 10E 5% 1W 10X4MM
*R11 HI 032-32220-00 RES M/F PWR 22E 5% 1W 12X4.5MM
R30 030-53100-20 RES FILM AI 100E 5% 0.4W 4X1.6MM
R31 030-53100-20 RES FILM AI 100E 5% 0.4W 4X1.6MM
R32 030-02820-20 RES FILM 82E 5% 0.4W 4X1.6MM
R33 030-02820-20 RES FILM 82E 5% 0.4W 4X1.6MM
*R34 LOW 032-33180-01 RES M/F PWR 180E 5% 2.5W 17X5MM
*R34 MID 032-33180-01 RES M/F PWR 180E 5% 2.5W 17X5MM
*R34 HI NOT FITTED
*R35 LOW 032-33180-01 RES M/F PWR 180E 5% 2.5W 17X5MM
*R35 MID 032-33180-01 RES M/F PWR 180E 5% 2.5W 17X5MM
*R35 HI NOT FITTED
R36 036-13680-00 RES M/F 0805 CHIP 680E 5%
R37 036-14100-00 RES M/F 0805 CHIP 1K 5%
R38 036-17100-00 RES M/F 0805 CHIP 1M 5%
R42 036-15100-00 RES M/F 0805 CHIP 10K 5%
RV43 042-05470-09 RES PRESET 50K CERMET 9.5MM SQ FLAT
R44 036-14470-00 RES M/F 0805 CHIP 4K7 5%
R47 036-16100-00 RES M/F 0805 CHIP 100K 5%
RV48 042-04500-08 RES PRESET 5K CERMET 9.5MM SQ FLAT
R49 036-13680-00 RES M/F 0805 CHIP 680E 5%
R50 036-13680-00 RES M/F 0805 CHIP 680E 5%
RV52 042-04500-08 RES PRESET 5K CERMET 9.5MM SQ FLAT
R55 036-17100-00 RES M/F 0805 CHIP 1M 5%
R56 036-15100-00 RES M/F 0805 CHIP 10K 5%
RV57 042-05470-09 RES PRESET 50K CERMET 9.5MM SQ FLAT
R58 036-14470-00 RES M/F 0805 CHIP 4K7 5%
R61 036-13220-00 RES M/F 0805 CHIP 220E 5%
R62 036-14100-00 RES M/F 0805 CHIP 1K 5%
*RV63 LOW 044-04200-03 RES PRESET MULTITURN 2K 10T PNL MTG
*RV63 MID 044-04200-03 RES PRESET MULTITURN 2K 10T PNL MTG
*RV63 HI 044-04200-03 RES PRESET MULTITURN 2K 10T PNL MTG
R64 036-14470-00 RES M/F 0805 CHIP 4K7 5%
R67 036-15100-00 RES M/F 0805 CHIP 10K 5%
R68 036-14470-00 RES M/F 0805 CHIP 4K7 5%
R69 036-12100-00 RES M/F 0805 CHIP 10E 5%
RV69 042-04220-02 RES PRESET 2K CERMET 9.5MM SQ FLAT
R70 036-13220-00 RES M/F 0805 CHIP 220E 5%
R72 045-04470-01 RES NTC 4K7 20% 5MM DISC
R73 036-16220-00 RES M/F 0805 CHIP 220K 5%
RV74 042-05100-10 RES PRESET 10K CERMET 9.5MM SQ FLAT
R77 036-14220-00 RES M/F 0805 CHIP 2K2 5%
R78 036-14100-00 RES M/F 0805 CHIP 1K 5%
R80 036-13100-00 RES M/F 0805 CHIP 100E 5%
R81 036-14100-00 RES M/F 0805 CHIP 1K 5%
R82 036-14220-00 RES M/F 0805 CHIP 2K2 5%
R83 036-14100-00 RES M/F 0805 CHIP 1K 5%
R84 036-14220-00 RES M/F 0805 CHIP 2K2 5%
R85 036-14100-00 RES M/F 0805 CHIP 1K 5%
R86 036-14100-00 RES M/F 0805 CHIP 1K 5%
R87 036-15100-00 RES M/F 0805 CHIP 10K 5%
R88 036-15100-00 RES M/F 0805 CHIP 10K 5%
R89 039-02500-01 DUMMY LOAD 50E 1% 10W TO-220 NIKKOHM
R90 039-02500-01 DUMMY LOAD 50E 1% 10W TO-220 NIKKOHM
R91 039-02500-01 DUMMY LOAD 50E 1% 10W TO-220 NIKKOHM
R92 039-02500-01 DUMMY LOAD 50E 1% 10W TO-220 NIKKOHM
R93 039-02500-01 DUMMY LOAD 50E 1% 10W TO-220 NIKKOHM
R94 039-02500-01 DUMMY LOAD 50E 1% 10W TO-220 NIKKOHM
R95 036-14100-00 RES M/F 0805 CHIP 1K 5%
R96 036-14470-00 RES M/F 0805 CHIP 4K7 5%
R97 036-14100-00 RES M/F 0805 CHIP 1K 5%
R98 036-14390-00 RES M/F 0805 CHIP 3K9 5%
R99 036-14100-00 RES M/F 0805 CHIP 1K 5%
R100 036-14100-00 RES M/F 0805 CHIP 1K 5%
R101 036-12100-00 RES M/F 0805 CHIP 10E 5%
R102 036-16220-00 RES M/F 0805 CHIP 220K 5%
R103 036-15330-00 RES M/F 0805 CHIP 33K 5%
R104 036-15150-00 RES M/F 0805 CHIP 15K 5%
R105 036-16470-00 RES M/F 0805 CHIP 470K 5%
R106 036-15150-00 RES M/F 0805 CHIP 15K 5%
R107 036-14390-00 RES M/F 0805 CHIP 3K9 5%
R108 036-15100-00 RES M/F 0805 CHIP 10K 5%
R109 036-14330-00 RES M/F 0805 CHIP 3K3 5%
R110 036-16100-00 RES M/F 0805 CHIP 100K 5%
R111 036-16220-00 RES M/F 0805 CHIP 220K 5%
R112 036-16220-00 RES M/F 0805 CHIP 220K 5%
R113 036-15270-00 RES M/F 0805 CHIP 27K 5%
R115 036-16470-00 RES M/F 0805 CHIP 470K 5%
R116 045-04470-01 RES NTC 4K7 20% 5MM DISC
R117 036-15150-00 RES M/F 0805 CHIP 15K 5%
R118 036-14390-00 RES M/F 0805 CHIP 3K9 5%
R119 036-14820-00 RES M/F 0805 CHIP 8K2 5%
R120 036-14680-00 RES M/F 0805 CHIP 6K8 5%
R121 036-14100-00 RES M/F 0805 CHIP 1K 5%
R122 036-14100-00 RES M/F 0805 CHIP 1K 5%
R123 036-13470-00 RES M/F 0805 CHIP 470E 5%
R124 036-13220-00 RES M/F 0805 CHIP 220E 5%
SK1 240-02100-44 SKT COAX MINI JACK PCB MTG ANGLED
