Tait T850 II Series User Manual

IPN 220-01159-01
D5.3.8
T859 PCB Information M850-00
31/09/98 Copyright TEL
IPN Legend Description IPN Legend Description
T859 Mechanical & Miscellaneous Parts (220-01159-01)
012-04100-05 30 CAP F/THRU 1N SUPPR FLTR S-MTG
065-00010-20 BEAD FERRITE BALUN 4B1 PHILIPS
Placed on DC+ power cables.
070-01001-00 23 D-RANGE 15 WAY COMPL T800
070-02003-00 LED RED COMPL T800 PA
“High Rev/Low Fwd Power” LEDs - D11/D5
070-02004-00 LED GREEN COMPL T800 PA
“Supply” LED - D10
201-00030-01 WIRE T/C 7/0.2 PVC BROWN
Forward power alarm.
201-00030-03 WIRE T/C 7/0.2 PVC ORANGE
Reverse power meter.
201-00030-04 WIRE T/C 7/0.2 PVC YEL
Reverse power.
201-00030-05 WIRE T/C 7/0.2 PVC GRN
Forward power meter.
201-00030-06 WIRE T/C 7/0.2 PVC BLUE
Tx-Key.
201-00030-07 WIRE T/C 7/0.2 PVC VIOLET
Reverse power alarm.
201-00030-09 WIRE T/C 7/0.2 PVC WHITE
Temperature sense.
201-00030-10 WIRE T/C 7/0.2 PVC BLACK
Forward power.
201-00050-12 AUTO 152 RED 28/0.3 PVC
DC+ from D-range PCB.
201-00050-20 AUTO 152 BLACK 28/0.3 PVC
DC- from D-range PCB.
219-02592-00 CABLE ASSY RG223/U N TO BNC
Exciter/PA connecting cable.
219-02599-00 CABLE ASSY PA INPUT REAR DRIVE
RF input cable/connector assembly.
220-01152-00 2 PCB T858/859 DIRNL COUPLER
220-01159-01 1 PCB T859 100W PA A1C674
240-02100-06 26 SKT COAX N TYPE PNL MTG OP-TER
240-02100-17 27 SKT COAX BNC PNL JAC CRP RG316
Part of 219-02599-00 sub-assembly.
240-06010-15 25 BLOCK LATCHING 15W D RANGE
258-00010-03 31 FAN 12V 119X119X25MM TUBE AX
302-05204-00 29 BRKT A3M2314 F/THRU MTG T859
303-23117-00 44 COVER SIDE COMPL A2M2223
303-50005-00 36 CONTACT A4M2311 SPRING EARTH
308-01007-01 38 HANDLE BASE STATION SERIES II
308-13085-01 4 HSINK DIECAST T858 50W PA
308-13086-00 19 HSINK A3M2271 2MM W/LINE PA
316-06651-00 37 PNL PA NO INP DRV SER II DBL
316-85018-00 27 PIN A4M1397 COAX CONDUCTOR
319-01147-00 3 SHIELD A3M2224 WALL T859 PA
319-01148-00 35 SHIELD A3M2225 LID T859 PA
319-30033-00 13 SPACER A4M1339 UHF PA
345-00040-16 24 SCRW M3X20MM P/POZ ST BZ
349-00020-07 6 SCRW 4-40 X 5/16 P/POZ T/T BLK
349-00020-09 11 SCRW T/T 4-40X3/8 IN P/POZ BLK
349-00020-36 43 LIM)SCREW TT M3X8m PANTORX BLK
349-00020-43 34 SCRW T/T M4X12MM P/POZ BZ
349-00020-49 32 SCRW T/T M4X35MM P/POZ BZ
349-00020-50 21 SCRW T/T 4-40 * 5/8 P/POZ BLK
352-00010-29 40 NUT M4 NYLOC HEX
352-00010-35 15 NUT 8-32 UNC HEX XSTR MTG
353-00010-10 10 WSHR M3 FLAT 7MM*0.6MM ST BZ
353-00010-24 39 WSHR M4x8mm Flat
356-00010-01 18 TAG SOLDER 3MM SHORT M6132/3.2
356-00010-03 5 TAG SOLDER 3MM LONG M614/3.2
357-00010-45 33 CLAMP CABLE 4.8MM P CLIP
360-00010-41 42 BUSH SHORTY BLK
362-00010-07 7 GASKET SIL INSULATING TO-220
362-00010-13 9 BUSH INSULATING 1.1MM TOP HAT
362-00010-33 41 GROMMET LED MTG 3MM
365-00100-20 LABEL WHITE S/A 28X11MM
365-01540-00 LABEL PA TYPE APPL/SERIAL NO
369-00010-14 TIE CABLE NYLON 100*2.6MM
399-00010-51 BAG PLASTIC 75*100MM
400-00020-07 SLEEVING 2MM SIL RUBBER
400-00020-09 SLEEVING 3MM SIL RUBBER
400-00020-30 HEATSHRINK 3MM
410-00010-43 PKG T296 AMPAC REF 73-46
Note
The following electrical components are also included in the
mechanical assembly drawing to help identify certain mechani-
cal components.
000-00022-71 14 (S) XSTR SD1135 NPN STUD MTG UHF PWR
5W - Q1
000-00030-95 8 (S) XSTR 2N6107 PNP TO-220 AF PWR - Q16
000-00032-79 16 (S) XSTR MRF654 UHF PWR 15W STUD - Q3
000-00032-67 17 (S) XSTR MRF648 UHF PWR 60W 6LFL
Q4, Q6, Q7
039-02500-01 12 DUMMY LOAD 50E 1% 10W TO-220
NIKKOHM - R89/90/91/92/93/94
051-00005-39 20 COUPLER WIRELINE TAIT COIL DWG NO
539 - L19
051-00005-54 22 COUPLER WIRELINE TAIT COIL DWG NO
554 - L39
