Tait T850 II Series User Manual

IPN 220-01145-02
E2.4
T850 VCO PCB Information M850-00
31/09/98 Copyright TEL
Ref Var IPN Description Ref Var IPN Description
*C1 A 015-21150-01 CAP CER 0805 CHIP 1P5 +/-0.25P NPO 50V
*C1 B 015-21180-01 CAP CER 0805 CHIP 1P8 +/-0.25 NPO 50V
*C1 C 015-21220-01 CAP CER 0805 CHIP 2P2 +/-0.25P NPO 50V
*C1 D 015-21220-01 CAP CER 0805 CHIP 2P2 +/-0.25P NPO 50V
C2 025-08100-02 CAP TANT BEAD 10M 10% 16V
C3 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C4 015-21100-01 CAP CER 0805 CHIP 1PO +/-0.25P NPO 50V
C5 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C6 028-02110-00 LH)CAPTRM1.2-11P10T PISTONPREC
*C7 A 015-21680-01 CAP CER 0805 CHIP 6P8 +/-0.25P NPO 50V
*C7 B 015-21470-01 CAP CER 0805 CHIP 4P7 +/-0.25P NPO 50V
*C7 C 015-21680-01 CAP CER 0805 CHIP 6P8 +/-0.25P NPO 50V
*C7 D 015-21820-01 CAP CER 0805 CHIP 8P2 +/-0.25P NPO 50V
*C8 A 015-22270-01 CAP CER 0805 CHIP 27P 5% NPO 50V
*C8 B 015-22270-01 CAP CER 0805 CHIP 27P 5% NPO 50V
*C8 C 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
*C8 D 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C9 015-23120-01 CAP CER 0805 CHIP 120P 5% NPO 50V
C10 015-21180-01 CAP CER 0805 CHIP 1P8 +/-0.25 NPO 50V
C11 015-21330-01 CAP CER 0805 CHIP 3P3 +/-0.25P NPO 50V
C12 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C13 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C14 015-23120-01 CAP CER 0805 CHIP 120P 5% NPO 50V
C16 015-23120-01 CAP CER 0805 CHIP 120P 5% NPO 50V
C17 015-23120-01 CAP CER 0805 CHIP 120P 5% NPO 50V
C18 015-22220-01 CAP CER 0805 CHIP 22P 5% NPO 50V
C19 015-05470-08 CAP CER 1206 CHIP 47N 10% X7R 50V
C21 015-23120-01 CAP CER 0805 CHIP 120P 5% NPO 50V
C22 015-23120-01 CAP CER 0805 CHIP 120P 5% NPO 50V
C23 015-21820-01 CAP CER 0805 CHIP 8P2 +/-0.25P NPO 50V
C24 015-05470-08 CAP CER 1206 CHIP 47N 10% X7R 50V
D1 001-00012-63 (S) DIODE VARICAP BB809
D2 001-00012-63 (S) DIODE VARICAP BB809
L1 056-00021-60 IND FXD 330NH 6.6X2.7MM AXIAL NON MAGNET
L2 056-00021-60 IND FXD 330NH 6.6X2.7MM AXIAL NON MAGNET
L3 056-00021-60 IND FXD 330NH 6.6X2.7MM AXIAL NON MAGNET
L4 056-00021-60 IND FXD 330NH 6.6X2.7MM AXIAL NON MAGNET
L5 052-08135-35 COIL A/W 3.5T/3.5MM HOR 0.8MM WIRE
PL2 240-00025-36 PLUG 32WAY 1ROW PC MTG HARWIN
PL3 240-00025-36 PLUG 32WAY 1ROW PC MTG HARWIN
PL4 240-00025-36 PLUG 32WAY 1ROW PC MTG HARWIN
PL5 240-00025-36 PLUG 32WAY 1ROW PC MTG HARWIN
Q1 000-10057-10 (S) XSTR SMD MMBR571 NPN SOT-23 UHF LO PW
Q2 000-10057-10 (S) XSTR SMD MMBR571 NPN SOT-23 UHF LO PW
Q3 000-10057-10 (S) XSTR SMD MMBR571 NPN SOT-23 UHF LO PW
Q4 000-10008-57 (S) XSTR SMD BCW70/BC857-215 PNP SOT23AF
Q5 000-00032-47 (S) XSTR MRF559 NPN XPACK UHF PWR 0.5W
R1 036-14390-00 RES M/F 0805 CHIP 3K9 5%
R2 036-14100-00 RES M/F 0805 CHIP 1K 5%
R3 036-13100-00 RES M/F 0805 CHIP 100E 5%
R4 036-12220-00 RES M/F 0805 CHIP 22E 5%
R5 036-12270-00 RES M/F 0805 CHIP 27E 5%
*R6 A 036-12820-00 RES M/F 0805 CHIP 82E 5%
*R6 B 036-12820-00 RES M/F 0805 CHIP 82E 5%
*R6 C 036-12820-00 RES M/F 0805 CHIP 82E 5%
*R6 D 036-13120-00 RES M/F 0805 CHIP 120E 5%
R7 036-14100-00 RES M/F 0805 CHIP 1K 5%
R8 036-12220-00 RES M/F 0805 CHIP 22E 5%
R9 036-14270-00 RES M/F 0805 CHIP 2K7 5%
R10 036-14120-00 RES M/F 0805 CHIP 1K2 5%
R11 036-13150-00 RES M/F 0805 CHIP 150E 5%
R12 036-12100-00 RES M/F 0805 CHIP 10E 5%
R13 036-12560-00 RES M/F 0805 CHIP 56E 5%
R14 036-13330-00 RES M/F 0805 CHIP 330E 5%
R15 036-12100-00 RES M/F 0805 CHIP 10E 5%
R17 036-14680-00 RES M/F 0805 CHIP 6K8 5%
R18 036-14180-00 RES M/F 0805 CHIP 1K8 5%
R19 036-14100-00 RES M/F 0805 CHIP 1K 5%
R20 036-12180-00 RES M/F 0805 CHIP 18E 5%
R21 036-13330-00 RES M/F 0805 CHIP 330E 5%
R22 036-12100-00 RES M/F 0805 CHIP 10E 5%
*TL1 A 051-00005-43 RESNTR TAIT NO 543 480-520MHZ T855/7
*TL1 B 051-00005-42 RESNTR TAIT NO 542 435-480MHZ T855/7
*TL1 C 051-00005-41 RESNTR TAIT NO 541 395-440MHZ T855/7
*TL1 D 051-00005-40 RESNTR TAIT NO 540 355-395MHZ T855/7
065-00010-13 BEAD FERRITE 7D 1.9*0.9*3.8MM STACK POLE
Place On Lead Of L4, Secure With Loctite 454-16 Gel
220-01145-00 PCB T855/856/857 VCO
240-00026-32 PLUG 32WAY 1ROW PC MTG HARWIN
345-00040-10 SCREW M3*6MM PAN POZI ST BZ
350-00016-42 SPACER 5MM HI 8MM X M3 STUD 2.5MM X M3
353-00010-10 WASHER M3 FLAT 7MM*0.6MM ST BZ
353-00010-13 WASHER M3 SHAKEPROOF INT BZ
Variant
Code
Description
T855
(MHz)
T856/857
(MHz)
ATx Hi
g
h - 480-500
B Tx Mid/Rx Hi
g
h 480-520 440-480
C Tx Low/Rx Mid 440-480 400-440
D Rx Low 400-440 -
