M850-00

T800 Ancillary Equipment

Programming Kits

T800-01-0000

The T800-01-0000 kit is used for programming T800 Series II base station equipment

using a standard IBM

 (or compatible) PC.

The kit comprises the following items:

PGM800Win programming software user's manual

PGM800Win Windows

 based programming software on 3



" floppy discs

T800-01-0002 programming cable.

T800-01-0001

The T800-01-0001 kit is the same as the T800-01-0000 kit described above, but with the

addition of the T800-01-0004 module programming interface.

T800-01-0002

The T800-01-0002 programming cable connects the PC directly to the programming

socket on the T800 Series II rack frame speaker panel or backplane PCB, thus enabling

T800 Series II modules to be read or programmed while in the rack frame. It can also

connect to the programming socket on the T800-01-0004 programming module interface

if the module is to be read or programmed while out of the rack frame.

T800-01-0003

The T800-01-0003 programming kit contains a T800-01-0002 programming cable and a

T800-01-0004 programming module interface.

T800-01-0004

The T800-01-0004 programming module interface is designed to allow a PC to connect

directly to a T800 Series II module. It comprises a small PCB on which is mounted a

D-range socket, a programming socket, a Micromatch socket and a DC input connector.

The T800-01-0004 plugs directly into D-range 1 or D-range 2 (selected by a switch on the

PCB), or into SK805 in the microcontroller compartment via the supplied ribbon cable

loom, and is then connected to the PC with a T800-01-0002 programming cable.

Refer to the T800 Ancillary Equipment Service Manual for more information.
