H14
T800 Ancillary Equipment
M850-00
31/09/98 Copyright TEL
Power Supplies
T800-23-0010 Mains Power Supply
The T800-23-0010 mains power supply is designed to power the T800-23-0000/0001
Slimline Repeaters and mounts on the front panel instead of the options tray. It requires
a mains input voltage (auto range) of 85-132/170-264V AC at 47-440Hz.
Refer to the T800 Ancillary Equipment Service Manual for more information.
T807-10-0000 Mains Power Supply
The T807-10-0000 is a switching power supply capable of supplying up to 15A at 11-14V
DC. It requires a mains supply of 230V/50Hz or 115V/60Hz (nominal values) which
can be internally selected with a switch. The T807-10-0000 is designed to power T800
Series II 50W transmitters (plus receivers, etc.) and requires a T800-44-0000 guide to fit
into a T800 Series II rack frame.
Refer to the T800 Ancillary Equipment Service Manual for more information.
T808-10-0000 Mains Power Supply
The T808-10-0000 is a switching power supply capable of supplying up to 25A at 11-14V
DC. It requires a mains supply of 230V/50Hz or 115V/60Hz (nominal values) which
can be internally selected with a switch. The T808-10-0000 is designed to power T800
Series II 100W transmitters (plus receivers, etc.) and requires a T800-44-0000 guide to fit
into a T800 Series II rack frame.
Refer to the T800 Ancillary Equipment Service Manual for more information.
